36 General Maintenance

Preparing for Packer Inspection

To prepare for packer inspection:
1. Park the vehicle on level ground and apply the parking brake.
2.
Using the joystick, fully extend the arm.
3.
Remove the tailgate safety pins (see Figure 3-21).
4.
Fully open the tailgate by pressing the T
(see Figure 3-22).
Keep this switch pressed until the tailgate is fully open.
5. Fully extend the packer by pressing the green P
(see Figure 3-23).
Danger!
Never enter the hopper while the packer is moving.
6. When the packer has reached its fully extended position, press the red E
on the packer control station (see Figure 3-25).
7.
Place the tailgate safety prop into service position.
Danger!
Always use the tailgate safety prop while working under a raised tailgate. The safety prop
should be used even if the tailgate is in fully raised position.
8.
Perform the lockout/tagout procedure (see Locking Out and Tagging Out the Vehicle on page 26).
U switch on the in-cab control panel
AILGATE P
button on the packer control station
ACK
S button
MERGENCY TOP
