116 Hydraulic System
Rotation can be done by turning the mounting cap clockwise or counter-clockwise with
your hands or by using a metallic bar as illustrated in the above picture.
N
: Make sure pump does not come apart.
OTE
N
: The cartridge will rotate with the housing.
OTE
Be sure not to pull on the mounting cap. Otherwise, the dowel pin may leave its position in the
I
:
MPORTANT
housing causing damage to the pump.
Put all 4 bolts back in place.
13 d.
Check if the shaft rotates freely.
13 e.
Tighten up all bolts to the torque of 138-140 ft-lb.
13 f.
When tightening bolts, be sure to respect the following number sequence to avoid
damaging the seals:
