Chapter 4
Multiplier
The sets the size multiplier of barcode. The range up to 16 and defaults to 6 if omitted.
Encoding Mode
Parameter used to specify the encoding mode of the Aztec code.
Video#_ECC%
Command used to specify the Video mode used and to select the ECC % level. The first
part of the parameter selects the video effect as listed below while the second portion
selects the Error Correction Code percentage. The values for the ECC% are 1 to 4.
ECC%
This parameter is used to set the Error Correction % level. This field is ignored if a
configuration parameter is selected.
LDS2 Programming Manual - 880019-0202
Configuration
143x143
147x147
151x151
Table 17 Aztec Configuration Values
Encoding Modes
0
1
2
Table 18 Aztec Encoding Modes
Video #
0
1
2
4
Table 19 Aztec Videos #
Description
Full Size
Full Size
Full Size
Standard
Reserved
GS1
Normal/OR
Reverse
XOR
Opaque
Barcodes
4-13
