Table 12 Data Matrix Configuration Parameters - Microcom LDS2 Programming Manual

Barcodes
Symbol Size
Auto
10 x 10
12 x 12
14 x 14
16 x 16
18 x 18
20 x 20
22 x 22
24 x 24
26 x 26
32 x 32
36 x 36
40 x 40
44 x 44
48 x 48
52 x 52
64 x 64
72 x 72
80 x 80
88 x 88
96 x 96
104 x 104
120 x 120
132 x 132
144 x 144
8 x 18
8 x 32
12 x 26
12 x 36
16 x 36
16 x 48
Table 12
Encoding
The Encoding parameter used to set the encoding scheme that will be used for the supplied
data. The printer default is set to "Auto", which will automatically switch to the most efficient
encoding scheme for the data provided. Refer to Table 8 for the valid choices for the
4-6
Numeric Alphanumeric
Capacity Capacity
--- ---
6 3
10 6
16 10
24 16
36 25
44 31
60 43
72 52
88 64
124 91
172 127
228 169
288 214
348 259
408 304
560 418
736 550
912 682
1152 862
1392 1042
1632 1222
2100 1573
2608 1954
3116 2335
10 6
20 13
32 22
44 31
64 46
98 72
Data Matrix Configuration Parameters
Binary Byte
Capacity
---
1
3
6
10
16
20
28
34
42
60
84
112
142
172
202
278
366
454
574
694
814
1048
1302
1556
3
8
14
20
30
47
