Printer Specifications
CI - Font Name
@bold_10
@normal_12
@bold_12
@normal_14
@bold_14
@normal_16
@bold_16
@normal_20
@bold_20
@normal_24
@bold_24
@ocra_12
@ocrb_08
@ocrb_12
Font File Type Example:
If a normal 8 point font is desired then "@normal_08" should be entered for the CI parameter in
order for the proper font to be printed. Fonts are accessed by entering the system character "@",
font name followed by the underscore character and then the point size into the CI parameter.
Line Draw
The line draw feature selected by entering "@line" into the CI parameter. The line draw feature
easily creates lines by using the XB and YB coordinates as an insertion point for the line to start and
then adjusting the SW and SH parameters to define the width and the height of the line.
Line Draw Example:
^A)
^D200)3.3, 1.9, 0.125, 1.063, 5, 1
^F1)1.0, 1.0,@line, 1.11, 0.01
^F1)1.0, 1.0,@normal_14
^T1)Line Draw Feature
^D300)1
^Z)
1-8
10 Point – 01234567890ABCDEFGHIJKLMNOPQRSTUVWXYZa
12 Point – 01234567890ABCDEFGHIJKLMNOPQRSTUVWXYZab
12 Point – 01234567890ABCDEFGHIJKLMNOPQRSTUVWXYZa
14 Point – 01234567890ABCDEFGHIJKLMNOPQRSTU
14 Point – 01234567890ABCDEFGHIJKLMNOPQRST
16 Point – 01234567890ABCDEFGHIJKL
16 Point – 01234567890ABCDEFGHIJKL
20 Point – 01234567890ABCDEFGHIJ
20 Point – 01234567890ABCDEFGHI
24 Point – 0123456ABCDEGabc
24 Point – 012345ABCabcdefgh
12 Point – 0123456789ABCDEFGHIJKLMNOPQRUSTUWXYZabc
8 Point – 1234567890ABCDEFGHIJKLMNOPQRSTUVWXZYabcdefghijklmnopqr
12 Point – 1234567890ABCDEFGHIJKLMNOPQRSTUV
Table 1 Resident Bitmapped Fonts
Font Sample
