This script inserts a line an inch from the left side and an inch from the bottom. The line would be
1.11" in width or length (X direction) and would be 0.01" in height (Y direction). The "^Fn)" field must
reference a "^Tn)" field for proper operation. The line draw does not have to reference its own
specific Text Entry command ("^Tn)") and may reference an existing Text Entry field in the script file
as demonstrated in the above example. Refer to Chapter 4 for additional information regarding the
line draw feature.
Bar Codes
The bar codes or symbologies are stored in the printer and can be selected by entering the system
character "@" followed by the text equivalent code of the desired symbology in the CI parameter,
refer to Table 2 for the available bar codes.
The bar codes that provide optional check digits are accessed by entering "cs" immediately following
the bar code text equivalent code. This is helpful to meet the individual bar code specifications.
For example: If the user wanted to generate a human readable MSI1 that included the check digits,
"msi1cs_hr" would then be entered while "msi1_hr" would not include the check digits in human
readable form.
See Chapter 5 for more detailed information pertaining to bar codes and their individual formatting
requirements.
CI - Barcode Name
@codabar
@code128
@code128auto
@code39
@code93
@codei2of5
@msi0
@msi1
@msi2
@postnet
@uccean128
@data
@pdf417
@aztec
@qrcode
LDS2 Programming Manual – 880019-0202
Codabar
Code 128 using manual compression
Code 128 using automatic compression
Code 3 of 9
Code 93
Code I2 of 5
Modified Plessey, User provides both check digits
Modified Plessey, User provides one check digit
Modified Plessey, User provides no check digits
POSTNET
UCC/EAN 128
Data Matrix 2D Bar code
PDF417 2D Bar code
Aztec 2D Bar code
QR Code Bar code
Table 2 Bar Code Index
Printer Specifications
Bar code Type
1-9
