Die-Cut/Blowhole Threshold Calculation Example; Figure 10 ^D900 Blackline Threshold Example - Microcom LDS2 Programming Manual

Printer Commands
300
On-Screen Sensor
value
250
200
150
100
Threshold – 128
(Factory Setting)
50
0
Figure 10
2.7.1.2

Die-Cut/Blowhole Threshold Calculation Example

Follow the process outlined below for an example to determine the die-cut/blowhole or
transmissive sensor threshold calculation. The values reported will vary depending on the
different types of media used.
LDS2 Programming Manual - 880019-0202
^D900 Blackline Threshold Example
Chapter 2
Grey indicates
acceptable
Threshold values
2-29
