Printer Commands
the takeup motor on after the print motor. The range is -1.0 to 1.0
seconds.
n2 The n2 sets the post takeup timing. This timing is a timeout on when to
turn off the takeup motor after printing. If using dispense mode
(^D597)1) of one, the take will stop after the label is removed. The
range is 0.0 to 10.0 seconds.
2.5.2 ^D630)n1, n2
Command used to set the optional takeup motor reverse timing. If used, the takeup motor
will reverse for the set timing. This is helpful on systems that are using an advance retract
command and need to reverse the media. The D729 command controls the enablement of
this takeup control and must be enabled before this command functions.
n1 Positive value turns the takeup motor on before the stock is retracted.
A value of zero turns the takeup motor on at the same time as stock
retraction. The range for n1 is 0.0 to 10.0 seconds.
n2 Positive value turns the take up off when the stock retraction completes
and sets a pause for the motor to settle. Negative values turn the
takeup motor off before stick retraction completes. A value of zero
turns the take up motor off when stick retraction completes.
2.5.3 ^D631)n
This command specifies the width of the media using the current selected prevailing unit of
measure selected by the "^D564)" command. The maximum width is the width of the print
head installed on the printer. This command is also a parameter in the "^D200)" script
header command. See also, LSX.
2.5.4 ^D632)n
This command specifies the height of the media using the current selected prevailing unit of
measure selected by the "^D564)" command. The maximum LSY height is 24". This
command is also a parameter in the "^D200)" script header command. See also, LSY.
2.5.5 ^D633)n
This command sets the height distance, as viewed inside the printer, of the registration mark
that identifies the label and/or tag size and is entered using the current selected prevailing
unit of measure selected by the "^D564)" command. This would be the backing material
found between die-cut labels, blowhole sense mark, and/or the blackline height. This
command is also a parameter in the "^D200)" script header command. See also, GAP.
2.5.6 ^D634)n
This command is only used when the registration mark is not located at the edge of the
media. The "DRM" is the distance from the leading edge of the media to the beginning of
the registration mark and is entered using the current selected unit of measure. This
command is also a parameter in the "^D200)" script header command. See also, DRM.
LDS2 Programming Manual - 880019-0202
(Set Takeup Motor Reverse Timing)
(Set Media Width)
(Set Media Height)
(Set GAP Size)
(Distance To Registration Mark)
