Chapter 2
630021-0000
630020-0000
630019-0000
630014-0000
630017-0000
2.5.20 ^D648)n
The "^D648)" command is used to set the blackline sensor to print head distance at the
factory. This command is a "property" which means that it controls a specific distance that
is set at the factory. The property commands may be set back to their default values using
the "^D392)1" command.
2.5.21 ^D649)n
The "^D649)" command is used to set the gap sensor to print head distance at the factory.
This command is a "property" which means that it controls a specific distance that is set at
the factory. The property commands may be set back to their default values using the
"^D392)1" command
2.5.22 ^D650)n
Sets the AGD or Activate Gap Detector header value. The AGD is the distance that the
printer will move with the registration sensors disabled. This feature is useful when preprint
text or other marks might trigger false detection. The value for "n" uses the prevailing units
configured by the ^D564 command.
2.5.23 ^D655)n
This command gives the user the ability to set a count down counter specified as "Labels
Printed" on the printer that is reported either by issuing the "^D655)" without a parameter, a
^D655)?, or "^D324)" (List Statistics) command.
If the value for 'n' is set to a negative (-1), the command is disabled. A positive value for 'n'
sets a countdown counter and once 0 is reached, the printer status would report a 0x14 or
>PM< depending on the ^D550 status selection. This >PM< is a status message that the
host system could trigger on to instruct the user to perform some preventative maintenance.
2.5.24 ^D670)
The "^D670)" command is used to configure the serial port. The command starts with the
"^D670)" and is then followed by four parameters or arguments. The first parameter must
be separated from the ^D command by a space and the following parameters must be
separated from each other using the comma delimiter. The command is entered using
following structure, ^D670) b, p, d, s. When changing the serial parameters, the host needs
to be set to the new serial parameters that take effect immediately after setting. If the host
parameters are not changed to the correct settings, the host and the printer will not
2-22
3" 300 DPI
4" 203 DPI
4" 300 DPI
4" 203 DPI
4" 300 DPI
Table 7 Print Head Parameters
(Set Blackline Sensor to Print Head Distance)
(Set Gap Sensor to Print Head Distance)
(Set AGD Value)
(Set Labels Printed)
(Set Serial Port)
Printer Commands
960
832
1280
832
1280
LDS2 Programming Manual - 880019-0202
12
8
12
8
12
