Printer Commands
one item from the numbered listing to report only its current value followed by a CR+LF
(0x0D+0x0A) used for termination. The "^D945)" command listing is continually updated to
provide additional information but all new information is added to the end of the listing for
backwards compatibility.
2.7.6 ^D960)n
This command causes the printer to print diagonal lines used to verify the condition of the
dots on the print head. The diagnostic pattern prints using the previous scripts configuration
or the media layout ^D63x persistent command settings if a script has not yet been
processed. The "^D960)1" is the serialized version of the "^K" immediate control code.
1 Diagonal Lines
2 2-On 30-Off Vertical Lines
3 5x5 Checkers
4 50% Grey (1x1 checkers)
2.7.7 ^D971)n
The "^D971)" command is used to enter, reset, and/or change the Inches Printed statistics
field. This statistic is only incremented while the printer is actually printing. The Inches
Printed statistic is used to record the print use of the printer between service periods and is
reset to "0" when service and/or repair is completed. The "^D971)" command is available in
access modes SERVICE and higher.
2.7.8 ^D972)n
This command is used to enter the total inches run or motor movement statistic of the
printer. The "^D972)" command is only set at the factory and is only reset if the printer's
CPU is replaced. The total inches run is used for warranty replacement of the print head
and its value should be recorded when a new print head is installed in the unit. This
command is only available in FACT mode, as it is the printer's odometer.
2.7.9 ^D973)n
The "^D973)" command is used to enter, reset, and/or change the Power on Time statistics
field. This statistic is only incremented while the printer is actually on. The Power on Time
statistic is used to record time the printer is powered and in only set at the factory. The
"^D973)" command is only available in FACT mode.
2.7.10 ^D974)n
This command is used to enter the Head Up cycle's statistic of the printer. The "^D974)"
command is only set at the factory and is never reset. This command is only available in
FACT mode. This statistic field is only available on models that contain head up detection.
2.7.11 ^D975)n
The "^D975)" command is used at the factory for the initial setup. This command resets all
of the statistical parameters to "0". This command is only available in modes FACT access
mode.
2.7.12 ^D976)n
This command is used to enter serial number of the printer manually at the factory. This
command is only available in modes FACT access mode.
LDS2 Programming Manual - 880019-0202
(Print Test Pattern)
(Edit Inches Printed Statistic)
(Edit Total Inches Run Statistic)
(Edit Power on Time Statistic)
(Edit Head Up Cycles Statistic)
(Clear All Statistics)
(Edit Unit Serial Number)
Chapter 2
2-33
