7.3.6.

Network

Feature
Network Stack
Network Stack
PCH LAN Controller
Wake on LAN
AMT Configuration
Intel AMT
BIOS Hotkey Pressed
MEBx Selection Screen
Hide Un-Configure ME Confirmation
MEBx Debug Message Output
Un-Configure ME
Amt Wait Timer
Disable ME
ASF
Activate Remote Assistance Process
USB Configure
PET Progress
AMT CIRA Timeout
Watchdog
OS Timer
BIOS Timer
Options Description
Info only
Enabled Enable/Disable UEFI network stack.
Disabled
Enabled Enable/Disable onboard NIC.
Disabled
Enabled Enable/Disable integrated LAN to wake the system. (The Wake On
Disabled LAN cannot be disabled if ME is on at Sx state.
Info only
Enabled Enable/Disable Intel (R) Active Management Technology BIOS
Disabled Extension.
Enabled Enable/Disable BIOS hotkey press.
Disabled
Enabled Enable/Disable MEBx selection screen.
Disabled
Enabled Hide Un-Configure ME without password Confirmation Prompt.
Disabled
Enabled Enable MEBx debug message output.
Disabled
Enabled Un-Configure ME without password.
Disabled
0 Set timer to wait before sending ASF_GET_BOOT_OPTIONS.
Enabled Set ME to Soft Temporary Disabled.
Disabled
Enabled Enable/Disable Alert Specification Format.
Disabled
Enabled Trigger CIRA boot.
Disabled
Enabled Enable/Disable USB Configure function.
Disabled
Enabled User can Enable/Disable PET Events progress to recieve PET
Disabled events or not.
0 OEM defined timeout for MPS connection to be established. 0 - use
the default timeout value of 60 seconds. 255 - MEBX waits until the
connection succeeds.
Enabled Enable/Disable WatchDog Timer.
Disabled
Set OS watchdog timer.
Set BIOS watchdog timer.
