7.2.

Main

The Main Menu provides read-only information about your system and also allows you to set the System Date and Time. Refer
to the tables below the screen shot of this menu for details of the submenus and settings.
7.2.1.

System Information

Feature
BIOS Version
Board Revision
Build Date and Time
7.2.2.

Processor Information

Feature
CPU Brand String
Frequency
Processor ID
Stepping
Number of Processors
GT Info
IGFX VBIOS Version
Total Memory
7.2.3.

PCH Information

Feature
PCH NAME
PCH SKU
Stepping
ME FW Version
ME Firmware SKU
System Management
Page 52
Options
Info only
Info only
Info only
Options
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Options
Info only
Info only
Info only
Info only
Info only
Submenu
Description
ADLINK BIOS version.
Hardware revision.
ADLINK date the BIOS was build.
Description
Display CPU Brand Name.
Display CPU Frequency.
Display CPU ID.
Display CPU Stepping.
Display number of Processors.
Display GT info of Intel Graphics.
Display VBIOS Version.
Display installed memory size.
Description
Display PCH name.
Display PCH SKU.
Display PCH stepping.
Display version of ME.
Display ME Firmware Kit SKU number.
