ADLINK Technology COM Express Express-BL User Manual page 70

7.3.11.1. Serial Port Console > Console Redirection Settings
Feature
Console Redirection Settings
Terminal Type
Bits per second
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Putty KeyPad
Redirection After BIOS Post
7.3.11.2. ICC Configuration
Feature
Turn off unused PCI/PCIe clocks
Clock Manipulation
Page 70
Options Description
Info only
VT100 Emulation: ANSI: Extended ASCII char set. VT100: ASCII char
set. VT100+: Extends VT100 to support color, function keys,
VT100+
etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto
VT-UTF8
1 or more bytes.
ANSI
9600 Selects serial port transmission speed.
19200
38400
57600
115200
7 Select Data Bits.
8
None Select Parity.
Even
Odd
Mark
Space
1 Select number of stop bits.
2
None Select flow control.
Hardware RTS/CTS
Disabled Enable VT-UTF8 Combination Key Support for ANSI/VT100
terminals.
Enable
Disabled With this mode enabled only text will be sent. This is to capture
Terminal data.
Enable
Disabled Enables or disables extended terminal resolution
Enable
80x24 On Legacy OS, the Number of Rows and Columns supported
redirection
80x25
VT100 Select FunctionKey and KeyPad on Putty.
LINUX
XTERMR6
SCO
ESCN
VT400
Always Enabled The Settings specify if BootLoader is selected than Legacy
console redirection is disabled before booting to Legacy OS.
BootLoader
Default value is Always Enable which means Legaacy console
Redirection is enabled for Legacy OS.
Options Description
Disabled Disabled: all clocks turned on.
Enable Enabled: clocks for empty PCI/PCIe slots will be turned off to
save power. Platform must be powered off for changes to take
effect.
Info only
