ADLINK Technology COM Express Express-BL User Manual page 17

Row A
Pin Name
A80 GND (fixed)
A81 LVDS_A_CK+
A82 LVDS_A_CK-
A83 LVDS_I2C_CK
A84 LVDS_I2C_DAT
A85
GPI3
A86 RSVD
A87 RSVD
A88 PCIE0_CK_REF+
A89 PCIE0_CK_REF-
A90 GND (fixed)
A91 SPI_POWER
A92
SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 TPM_PP
A97 TYPE10#
A98 SER0_TX / CAN_TX
A99
SER0_RX / CAN_RX
A100 GND (fixed)
A101 SER1_TX
A102 SER1_RX
A103 LID# **
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND (fixed)
Notes:
(1) 4-lane eDP is available as build option in place of LVDS and VGA
(2) PCIe port 7 is available by build option in place of GbE
Row B
Pin Name
B80 GND (fixed)
B81 LVDS_B_CK+
B82 LVDS_B_CK-
B83 LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85
VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED
B90 GND (fixed)
B91 VGA_GRN
B92
VGA_BLU
B93 VGA_HSYNC
B94 VGA_VSYNC
B95 VGA_I2C_CK
B96 VGA_I2C_DAT
B97 SPI_CS#
B98 RSVD
B99
RSVD
B100 GND (fixed)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP# **
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (fixed)
Row C
Pin Name
C80 GND (fixed)
C81 PEG_RX9+
C82 PEG_RX9-
C83 RSVD
C84 GND
C85
PEG_RX10+
C86 PEG_RX10-
C87 GND
C88 PEG_RX11+
C89 PEG_RX11-
C90 GND (fixed)
C91 PEG_RX12+
C92
PEG_RX12-
C93 GND
C94 PEG_RX13+
C95 PEG_RX13-
C96 GND
C97 RSVD
C98 PEG_RX14+
C99
PEG_RX14-
C100 GND (fixed)
C101 PEG_RX15+
C102 PEG_RX15-
C103 GND
C104 VCC_12V
C105 VCC_12V
C106 VCC_12V
C107 VCC_12V
C108 VCC_12V
C109 VCC_12V
C110 GND (fixed)
Express-BL
Row D
Pin Name
D80 GND (fixed)
D81 PEG_TX9+
D82 PEG_TX9-
D83 RSVD
D84 GND
D85 PEG_TX10+
D86 PEG_TX10-
D87 GND
D88 PEG_TX11+
D89 PEG_TX11-
D90 GND (fixed)
D91 PEG_TX12+
D92 PEG_TX12-
D93 GND
D94 PEG_TX13+
D95 PEG_TX13-
D96 GND
D97 RSVD
D98 PEG_TX14+
D99 PEG_TX14-
D100 GND (fixed)
D101 PEG_TX15+
D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND (fixed)
Page 17
