Feature
GTT LVDS/eDP Backlight Control
DDI function choose
Primary IGFX Boot Display
Select Secondary Display
LCD Panel Type
Active LFP
Panel Scaling
GT – Power Management Control
GT Info
RC6 (Render Standby)
GT OverClocking Support
7.3.4.

SATA

Feature
SATA Controller(s)
SATA Mode Selection
Page 60
Options
0%
20%
40%
60%
80%
100%
Display Port
HDMI
VBIOS Default
Disabled
VBIOS Default
640X480
800X600
1024X768
1280X1024
1400X1050
1600X1200
1366X768
1680X1050
1920X1200
1440X900
1600X900
1024X768 LVDS2
1280X800
1920X1080
2048X1536
No LVDS
Edp Port-A
Auto
Off
Force Scaling
Info only
Info only
Enabled
Disabled
Enabled
Disabled
Options
Enabled
Disabled
IDE
AHCI
RAID
Description
Actual backlight value in percent of the maximum setting.
Select DDI function choose to display port or HDMI.
Select the Video Device which will be activated during POS.
Select Secondary Display Device.
Select LCD panel used by Internal Graphics Device by selecting the
appropriate setup item.
Select the Active LFP Configuration.
Select the LCD panel scaling option used by the Internal Graphics
Device.
Display GT info of Intel Graphics.
Check to enable render standby support.
Enable/Disable GT OverClocking Support.
Description
Enable/Disable SATA Device.
Determines how SATA controller(s) operate.
