6.5.

PCI Configuration Space Map

Bus Number Device Number
00h 00h
00h 01h
00h 02h
00h 03h
00h 13h
00h 14h
00h 15h
00h 15h
00h 15h
00h 15h
00h 15h
00h 15h
00h 15h
00h 16h
00h 16h
00h 17h
00h 19h
00h 1Bh
00h 1Ch
00h 1Ch
00h 1Ch
00h 1Ch
00h 1Ch
00h 1Ch
00h 1Dh
00h 1Fh
00h 1Fh
00h 1Fh
00h 1Fh
Function Number Routing
00h N/A
00h Internal
00h Internal
00h Internal
00h Internal
00h Internal
00h Internal
01h Internal
02h Internal
03h Internal
04h Internal
05h Internal
06h Internal
00h Internal
01h Internal
00h Internal
00h Internal
00h Internal
00h Internal
01h Internal
02h Internal
03h Internal
04h Internal
05h Internal
00h Internal
00h N/A
02h Internal
03h Internal
06h Internal
Description
Intel host Bridge
Intel P.E.G Controller
Intel I.G.D
HD Audio Device
Instel Smart Sound Technology
Controller
xHCI Controller
Intel Serial I/O DMA Controller
Intel Serial I/O I2C Controller #0
Intel Serial I/O I2C Controller #1
Intel Serial I/O GSPI Controller #0
Intel Serial I/O GSPI Controller #1
Intel Serial I/O UART Controller #0
Intel Serial I/O UART Controller #1
Intel Management Engine Interface #1
Intel Management Engine Interface #2
SDIO Controller
Gigabit Etherent Controller
High Definition Audio controller
Intel PCI Express Root port 1
Intel PCI Express Root port 2
Intel PCI Express Root port 3
Intel PCI Express Root port 4
Intel PCI Express Root port 5
Intel PCI Express Root port 6
Intel USB EHCI Controller #1
Intel LPC Interface Bridge
SATA Host Controller #1
SMBus Controller
Thermal Controller
Express-BL
