ADLINK Technology COM Express Express-BL User Manual page 54

7.2.4.3. System Management > Power Consumption
Feature
Power Consumption
Current Input Current
Current Input Power
V3.30
V1.05
Vtt
V1.35
V5.00
V3.30
AIN7
7.2.4.4. System Management > Runtime Statistics
Feature
Runtime Statistics
Total Runtime
Current Runtime
Power Cycles
Boot Cycles
Boot Reason
7.2.4.5. System Management > Flags
Feature
Flags
BMC Flags
BIOS Select
ATX/AT-Mode
Exception Code
Page 54
Options Description
Info only
Read only Display input current.
Read only Display input power.
Read only Display actual voltage of the V3.30.
Read only Display actual voltage of the V1.05.
Read only Display actual voltage of the VTT.
Read only Display actual voltage of the V1.35.
Read only Display actual voltage of the V5.00.
Read only Display actual voltage of the V3.30.
Read only Display actual voltage of the AIN7.
Options Description
Info only
Read only The returned value specifies the total time in minutes the system
is running in S0 state.
Read only The returned value specifies the time in seconds the system is
running in S0 state.
This counter is cleared when the system is removed from the
external power supply.
Read only The returned value specifies the number of times the external
power supply has been shut down
Read only The Bootcounter is increased after a HW- or SW-Reset or after a
successful power-up.
Read only The boot reason is the event which causes the reboot of the
system.
Options Description
Info only
Read only
Read only Display the selection of current BIOS ROM.
Read only Display ATX/AT-Mode.
Read only System exception reason.
