7.4.

Boot

7.4.1.

Boot Configuration

Feature
Boot Configuration
Setup Prompt Timeout
Bootup NumLock State
Quiet Boot
Fast Boot
Boot Option Priorities

CSM Configuration

7.4.2. CSM Configuration
Feature
CSM Support
CSM16 Module Version
GateA20 Active
Option ROM Messages
Boot Option filter
Option ROM execution
Network
Storage
Video
Other PCI devices
Options
Info only
1
On
Disabled
Enabled
Disabled
Enabled
Info only
Submenu
Options
Enabled
Disable
Info only
Upon Request
Always
Force BIOS
Keep Current
UEFI and Legacy
Legacy only
UEFI only
Info only
Do not launch
Legacy only
UEFI only
Do not launch
UEFI only
Legacy only
Do not launch
UEFI only
Legacy only
UEFI OpROM
Legacy OpROM
Description
Enable/Disable the onboard SATA controllers.
Select SATA controller mode.
Enable/Disable the PATA port. In fact this enables or disables the
SATA channel on which the onboard SATA to PATA converter is
attached. When set to enabled the system boot will be delayed for
the time specified in PATA Port Detection Timeout if no PATA
device is connected.
Auto: Scan for PATA device and enable per default.
Define the maximum time to wait for drive detection on PATA port.
Description
This option controls if CSM will be launched.
UPON REQUEST - GA20 can be disabled using BIOS services.
ALWAYS - do not allow disabling GA20; this option is useful when
any RT code is executed above 1MB.
Set display mode for Option ROM.
This option controls what devices system can to boot.
Controls the execution of UEFI and Legacy PXE OpROM.
Controls the execution of UEFI and Legacy Storage OpROM.
Controls the execution of UEFI and Legacy Video OpROM.
For PCI devices other than Network, Mass storage or Video defines
which OpROM to launch.
Express-BL
Page 73
