3.3.16. General Purpose I/O (GPIO)
Signal
Pin #
Description
GPO[0]
A93
General purpose output pins.
GPO[1]
B54
General purpose output pins.
GPO[2]
B57
General purpose output pins.
GPO[3]
B63
General purpose output pins.
GPI[0]
A54
General purpose input pins.
Pulled high internally on the module.
GPI[1]
A63
General purpose input pins.
Pulled high internally on the module.
GPI[2]
A67
General purpose input pins.
Pulled high internally on the module.
GPI[3]
A85
General purpose input pins.
Pulled high internally on the module.
3.3.17. Serial Interface Signals
Signal
Pin #
Description
SER0_TX A98
General purpose serial port transmitter (TTL level output)
SER0_RX A99
General purpose serial port receiver (TTL level input)
SER1_TX A101
General purpose serial port transmitter (TTL level output)
SER1_RX A102
General purpose serial port receiver (TTL level input)
3.3.18. Power and System Management
Signal
Pin #
Description
PWRBTN#
B12
Power button to bring system out of S5 (soft off), active on falling edge.
SYS_RESET#
B49
Reset button input. Active low request for module to reset and reboot. May
be falling edge sensitive. For situations when SYS_RESET# is not able to
reestablish control of the system, PWR_OK or a power cycle may be used.
CB_RESET#
B50
Reset output from module to Carrier Board. Active low. Issued by module
chipset and may result from a low SYS_RESET# input, a low PWR_OK
input, a VCC_12V power input that falls below the minimum specification, a
watchdog timeout, or may be initiated by the module software.
PWR_OK
B24
Power OK from main power supply. A high value indicates that the power is
good. This signal can be used to hold off Module startup to allow carrier
based FPGAs or other configurable devices time to be programmed.
Page 26
I/O
PU/PD
O 3.3V
PU 10K 3.3V
O 3.3V
PU 10K 3.3V
O 3.3V
PU 10K 3.3V
O 3.3V
PU 10K 3.3V
I 3.3V
PU 10K 3.3V
I 3.3V
PU 10K 3.3V
I 3.3V
PU 10K 3.3V
I 3.3V
PU 10K 3.3V
I/O
PU/PD
O CMOS
I CMOS
O CMOS
I CMOS
I/O
I 3.3VSB
I 3.3V
O 3.3V
I 3.3V
Comment
After hardware RESET
output low
After hardware RESET
output low
After hardware RESET
output low
After hardware RESET
output low
Comment
Power rail tolerance 5V, 12V
There shall be PD on carrier
board
Power rail tolerance 5V, 12V
Power rail tolerance 5V, 12V
There shall be PD on carrier
board
Power rail tolerance 5V, 12V
PU/PD
Comment
PU 10k
3.3VSB
PU 10k 3.3V
PU 1K 3.3V
PU 100k
Should have
3.3VSB
weak pull up
