7.2.4.6. System Management > Power Up
Feature
Power Up
Power Up watchdog
Attention: F12 disables the Power Up
Watchdog.
ECO Mode
Power-up Mode
Attention: The Power-Up Mode only has effect,
if the module is in ATX-Mode.
7.2.4.7. System Management > LVDS Backlight
Feature
LVDS Backlight
LVDS Backlight Bright
7.2.4.8. System Management > Smart Fan
Feature
Smart Fan
CPU Smart FanTemperature Source
CPU Fan Mode
CPU Trigger Point 1
Trigger Temperature
PWM Level
CPU Trigger Point 2
Trigger Temperature
PWM Level
CPU Trigger Point 3
Trigger Temperature
PWM Level
CPU Trigger Point 4
Trigger Temperature
PWM Level
Options Description
Info only
Enabled The Power-Up Watchdog resets the system after a certain
Disabled amount of time after power-up.
Disabled Reduces the power consumption of the system.
Enable
Turn on Turn On: The machine starts automatically when the power
supply is turned on.
Remain off
Remain Off :To start the machine the power button has to be
Last State
pressed.
Last State: when powered on during a power failure the system
will automatically power on when power is restored
Options Description
Info only
255 The value range starts by 0 and ends by 255.
Options Description
Info only
CPU Sensor Select CPU smart fan source.
System Sensor
AUTO (Smart Fan) Select CPU Fan Mode.
Fan Off
Fan On
Read only
15 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
30 Select PWM level.
Read only
60 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
40 Select PWM level.
Read only
70 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
63 Select PWM level.
Read only
80 Specifies the temperature threshold at which the BMC turns on
CPU fan with specific PWM level.
100 Select PWM level.
