ADLINK Technology COM Express Express-BL User Manual page 68

Feature
Serial Port 2 Configuration
Serial Port
Device Settings
Change Settings
Device Mode
N5104D Super IO Configuration
Serial Port 1 Configuration
Serial Port
Device Settings
Change Settings
Serial Port 2 Configuration
Serial Port
Device Settings
Change Settings
Page 68
Options
Enabled
Disabled
IO=2F8h; IRQ=4
Auto
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Standard Serial Port Mode
IrDA Active pulse 1.6 uS
IrDA Active pulse 3/16 bit time
ASKIR Mode
Info only
Enabled
Disabled
IO=240h; IRQ=10
Auto
IO=240h; IRQ=10
IO=240h; IRQ=10,11,12
IO=248h; IRQ=10,11,12
IO=250h; IRQ=10,11,12
IO=258h; IRQ=10,11,12
Enabled
Disabled
IO=248h; IRQ=11
Auto
IO=248h; IRQ=11
IO=240h; IRQ=10,11,12
IO=248h; IRQ=10,11,12
IO=250h; IRQ=10,11,12
IO=258h; IRQ=10,11,12
Description
Enable/Disable Serial Port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO device.
Enable/Disable Serial Port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO device.
Enable/Disable Serial Port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO device.
