5-36. SYNCHRONIZER FORMAT
See Sec. "15-1. "Specifications" for the supported signal formats.
Item
Default
Format
Auto Detect
Setting
Format
1080
Standard
Frame/Field
59.94i
Rate
Level
Follow Input
Setting
Division
Follow Input
(FA-964K)
Horizontal
1920/3840
Size
Format
-
Setting
Selects the FS output format.
Auto Detect
Auto Detect: FS input signal format.
Manual
Manual: Signal format specified below
Specifies the vertical image resolution.
SD
720
2160 available with FA-964K in
1080
Simultaneous 4K/HD or 3D-LUT mode
2160
(FS1 only)
60p, 59.94p, 50p
48p, 47.95p
30p, 29.97p
25p, 24p, 23.98p
60i, 59.94i, 50i
Specifies the frame / field rate.
24PsF
23.98PsF
30PsF
29.97PsF
25PsF
Follow Input
Specifies the SDI mapping level.
Level A
Level B (Dual Link)
Follow Input
Specifies the SDI image division method.
SQD
Available in Simultaneous 4K/HD or 3D-
LUT mode (FS1 only)
2SI
Displays the horizontal image resolution
1920/3840
(Display only)
-
Displays the FS output format.
77
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1)
Description
