6-16. MADI OUTPUT SETTINGS

Allows you to set up MADI signal output.
Item Default
Mode 64ch Mode
Output Ch.33-
Silence
64

6-17. AES INPUT HYSTERESIS

Allows you to align timing of AES input channels by grouping them.
This function is useful for multi-channel audio input such as surround sound.
Item Default
Channels -
Hysteresis Disable
(*1)
If the reference audio is lost, the next smallest channel pair is used. Timing adjustment ranges within
±0.25 samples.
Channel pairs in a group should be the same sampling rate and synchronized with each other.
Required
option
Setting
56ch Mode
64ch Mode
Input Through
Output Disable
Silence
MADI In Ch.1-32
MADI In Ch.9-40
MADI In Ch.17-48
MADI In Ch.25-56
MADI In Ch.33-64
Setting
AES Ch. 1/2-7/8
OP(AES) Ch.1/ 2-7/8
Disable
Group A
Group B
100
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1 / EMB1)
FA-96MADI
Description
Selects an MADI signal output mode.
56ch Mode: 56-channel mode
64ch Mode: 64-channel mode
Input Through: Outputs MADI input
signal without change.
Output Disable: Outputs no MADI
signal.
Selects audio source for Ch 33-64 in
MADI output signal.
Silence: Silent signal
MADI In Ch.xx-xx: MADI input channel
sources whose sampling rate are to be
converted into 48kHz (for
synchronization with other channels).
Their gain and delay cannot be adjusted.
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1 / EMB1)
Description
Selects an AES input channel pair.
Selects an AES input channel pair.
(FA-96AES-UBL required)
Disable: Disables channel alignment.
Group A/B: Adds the channel pair to a
group (A or B) and aligns audio word
timing within the channel group by
referring to the smallest channel pair.
(*1)
