13. Event Data (CSV File)

Event data is stored in the computer as csv files, which are editable and allow you to change FA-9600
settings. The appendix explains syntax and rules of csv files and how to edit the files.
See "Appendix 2: Event Data List" for details on event contents.

13-1. Syntax and Rules


The file is line-based and each line represents each setting.
Each line requires a newline character (CRLF).

The following format is applied to each line.
"Category","Target","Item","Value"
* Do NOT enter any trailing or leading spaces on commas or "CRLF."
* Only alphanumeric characters and symbols (7-bit ASCII characters) are available.
* Strings are case sensitive.
Enter only strings and symbols listed in the Event Data List. (See "Appendix 2: Event Data
*
List.")
* CSV files must be encoded as 7-bit ASCII files.

13-2. Event Data Editing Example (Value Change)

For example, to change FS1 Video Level (see Sec. 5-1. "VIDEO PRE-/POST-PROCESS
AMPLIFIER") to 123.4%, there are two procedures as shown below.
◆
If using a new file:
(1) Create a csv file using a text editor.
(2) Type the text as shown below in the csv file. (See "Appendix 2: Event Data List" for details)
Process Amp,FS1,Pre Video Level,1234(newline character)
(3) Save the csv file as 7-bit ASCII. If using the Windows Notepad, select "ANSI" for the Encoding
menu to save the file.
(4) Import the csv file to FA-9600 using the Web GUI to apply the change.
See Sec. 12-5-4-1. "Importing / Exporting Events" for how to import events to the FA-9600.
◆
If using an existing event file:
(1) Export an event file from the FA-9600 to the Web GUI. Open the file using a text editor.
(See Sec. 12-5-4-1. "Importing / Exporting Events" for how to export events to the Web GUI.)
(2) Change the Value in the Process Amp,FS1,Pre Video Level,..." line to 1234.
(3)(4) (Same as above)
Event data example
|
