5-13. INPUT SELECT (Synchronizer)

<Simultaneous 4K/HD mode>
<3D-LUT mode>
Item Default
IN1 (FS1)
Source
Select
IN2 (FS2)
UHD Input
Link Single Link
(FA-964K)
Terminal
-
Assign
W/o FA-
964K
Loss Mode
W/ FA-
964K
Back Color Black
Loss Mode: When a part of 4K video signal (Quad Link 3G) is lost:
4K input Loss Mode setting
2-Sample
Back Color(Link)
Interleave
Setting
IN1
IN2
HDMI IN
EX3G IN1 to IN4
SFP RX1 to RX4
Single Link
Dual Link
Quad Link
-
Back Color
Back
Auto Freeze
Color
SDI Output Mute
Back Color(Link)
Back Color(Sep)
Auto Freeze
Back
SDI Output
Color
Mute(Link)
(Link)
SDI Output
Mute(Sep)
Black, Blue, Red,
Magenta, Green,
Cyan, Yellow
Output image when a part of input image is lost
Compensates the lost link and restores the whole image to
maintain its appearance.
51
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1)
Description
Selects a video signal input to FS1 or FS2.
EX3G IN1 to EX3G IN4: Require FA-
96EX3G44-R.
SFP RX 1 to SFP RX 4: Require FA-
96SFPC4.
Selects a UHD 4K SDI signal format.
Quad Link is enabled with FA-96EX3G44-
R or FA-96SFPC4 on Slot A. (FS1 only)
Displays the signal status that is selected
under Source Select (FS1 only).
Selects the output mode for input signal
loss.
Back Color: Outputs a monochrome (set
under Back Color below) video.
Auto Freeze: Freezes and outputs the last
normal video.
SDI Output Mute: Outputs no video signal
so that the FA-9600 downstream device
can detect video loss.
See the table below for 4K multi-link input.
Back Color (Link): Outputs a
monochrome (set under Back Color below)
video.
Back Color (Sep): Output the input video
displaying monochrome (set under Back
Color below) for the lost part.
SDI Output Mute(Link): Stops video
output if any one of four links is lost for
Quad Link video.
SDI Output Mute(Sep): Stops video output
if all four links are lost for Quad Link video.
Selects a monochrome used for Loss
Mode settings.
