- Page 1 OPERATION MANUAL MFR-9SDIR MFR-9SDOR 1st Edition...
-
Page 2: Upon Receipt
Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately. ◆ Option ITEM REMARKS MFR-9SDIR MFR-9SDOR Installation Guide This manual. -
Page 3: Prior To Starting
Prior to Starting MFR-9SDIR is an input card for MFR-4000R/MFR-6000R units. MFR-9SDOR is an output card for MFR-4000R/MFR-6000R units. ◆ Available Slots and Number for MFR-4000R Input / Output Cards Installable number Slot Slot number Installable cards of cards Input slot No.01-08 (INPUT1-8) -
Page 4: Matrix Size Chart
1. Matrix Size Chart 1-1. MFR-4000R ◆ Standard SDI Signal Routing Matrix size varies depending on the number of installed MFR-9SDIR and MFR-9SDOR cards as shown below. (72 x 72 to 9 x 9) Number of cards: MFR-9SDOR 72 x 72... - Page 5 1-2. MFR-6000R ◆ Standard SDI Signal Routing Matrix size varies depending on the number of installed MFR-9SDIR and MFR-9SDOR cards as shown below. (144 x 144 to 9 x 9) Number of cards: MFR-9SDOR...
- Page 6 2. [MFR-4000R] I/ O Card Installation / Replacement IMPORTANT Contact FOR-A agent or service center for I/O Card installation and replacement work since such work should only be conducted by qualified technical personnel. 2-1. How to Install a New Card The following procedure shows how to install an output card into OUTPUT1 slot.
- Page 7 Re-install the card stopper (Bottom) removed in Step 2. Hook the four hooks into the holes on the side of the card rail. Holes on the side of the card rail Four hooks Make sure that the four hooks are hooked on the rail bracket of the unit and fasten the four thumbscrews.
- Page 8 11. Turn the OUTPUT1 slot ON using [SETTING > SLOT SHUTDOWN] menu in Menu display. See MFR-4000R Operation Manual Sec. 4-2-2. “Turning ON/OFF an Input/ Output Card” for details. 12. Verify that LEDs on the card installed into OUTPUT1 light up. 13.
- Page 9 2-2. How to Replace a Card The following procedure shows how to replace a card in INPUT1 slot to a new input card. Detach all the BNC cables connected to the INPUT1 connector ports. ALARM SER IAL 232C REF IN INPUT OUTPUT INPUT1 slot...
- Page 10 3. [MFR-6000R] I/ O Card Installation / Replacement 3-1. How to Install a New Card The following procedure shows how to install an output card into OUTPUT1 slot. Unfasten to remove four fixing screws along the front panel as shown and detach the front panel.
- Page 11 Re-install the card stopper (B) removed in Step 2. Hook the four hooks into the holes on the side of the card rail. Holes on the side of the card rail Four hooks Make sure that the four hooks are hooked on the rail bracket of the unit and fasten the four thumbscrews.
- Page 12 3-2. How to Replace a Card The following procedure shows how to replace a card in INPUT9 slot to a new input card. Detach all the BNC cables connected to the INPUT9 connector ports. Unfasten to remove four fixing screws along the front panel and detach the front panel.
- Page 14 Tel: +1 352-371-1505 Fax: +1 714-894-5399 FOR-A Latin America and the Caribbean Miami Office Tel: +1 657-600-5759 FOR-A Latin America and the Caribbean Sao Paulo Office Tel: +55 (0)11-99913-3751 FOR-A Europe S.r.l. Via Volturno, 37, 20861, Brugherio MB, Italy Tel: +39 (0)39-916-4811 FOR A UK Limited Trident Court, 1 Oakcroft Road Chessington, KT9 1BD, U.K.
