12-2-4. Color Processor Source Select

Click Color Processor Source Select in the Video Block to display the menu as shown below.
* FS2 is not supported in 3D-LUT mode.
* Converter1 and Converter2 buttons and status are displayed with FA-96UDC option.
[Windows GUI]
[Web GUI]
Item Default
FS1 Color
Processor Synchronizer 1
Input Source
FS2 Color
Processor Synchronizer 2
Input Source
Setting
Synchronizer 1
Converter 1 Selects a source signal for FS1
Synchronizer 2 Color Processor.
Converter 2
Synchronizer 1
Converter 1 Selects a source signal for FS2
Synchronizer 2 Color Processor.
Converter 2
151
Description
