UPDATE GUIDE
FA-1010
Frame Synchronizer
FA-10RU
FA-10AES-BL/UBL/UBLC
FA-10ANA-AUD
FA-10GPI
FA-10DCCRU
nd
2
Edition
(FA-1010 Updater: Ver. 2.2.1 or higher)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA-1010 and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A FA-1010

Summary of Contents for FOR-A FA-1010

  • Page 1 UPDATE GUIDE FA-1010 Frame Synchronizer FA-10RU FA-10AES-BL/UBL/UBLC FA-10ANA-AUD FA-10GPI FA-10DCCRU Edition (FA-1010 Updater: Ver. 2.2.1 or higher)
  • Page 2 Edition Revision History FA-1010/FA-10RU/FA-10AES Update Guide Revision History Edit. Rev. Date Description Section 2014/02/05 First edition 2014/06/30 FA-10DCCRU update instruction added. 1, 2, 6 Figures replaced. 4, 5, 6, 7 Update notes added. 4, 5 Appendix added. Appendix A -F...

  • Page 3: Table Of Contents

    7. FA-10AES-BL/UBL Update ...................... 24 7-1. FPGA(FPGA 2) Update (PM 9224)(Required Time: 2min.) ..........24 7-2. CPLD Update (PM 9225) (Required Time: 30 sec.) ............25 Appendix A. Creating FA-1010 Backup Data ................26 A-1. Utility ..........................26 A-1-1. Event Control ......................26 A-1-1-1.
  • Page 4 D-2-1. Unit Status ........................3 Appendix E. Verifying the FA-10RU Version .................. 4 E-1. FA-10RU INFORMATION (Front Panel) ................4 E-2. Information (Web) ........................ 4 Appendix F. Verifying the FA-10DCCRU Version ................5 F-1. SYSTEM Setting (Front Panel) .................... 5 F-1-1.

  • Page 5: Equipment And System Requirements

    2. FA-1010 Updater 4. Hub 3. One crossover LAN cable, or 2 straight (Software) through LAN cables.  To update CPLD (FA-1010/FA-10RU/ FA-10DCCRU/FA-10AES) *Required only when updating CPLD. 2. Quartus Ⅱ 1.PC 3. Byte Blaster 4. 3x6 Phillips Programmer screwdriver...

  • Page 6: Workflow

    Sec. 5-3-7) [The FA-1010 IP address has been changed and is unknown] If the IP address has been changed and the new address is unknown, open the FA-1010 top panel, then set DIP switch DS2-3 to ON. (DS2 address on the card: W.5, 2.0) The FA-1010 can then be accessed using the default IP address (192.168.0.10).
  • Page 7  Initializing the FA-1010 1. Turn the power on while pressing down the INITIALIZATION button (Fig. 2). 2. The FA-1010 beeps when it is turned on. Continue pressing the button. Verify all LEDs on the front panel are lit during the initialization.
  • Page 8 “Connecting” will appear when the initialization is complete. 5) Reinstall backup data After the initialization is complete, reinstall the backup data to the FA-1010/FA-10RU/ FA-10DCCRU. Refer to the respective sections described under “Reference in Operation Manuals” in step 1) for details on how to reinstall backups.

  • Page 9: Hardware Option Installation

    3-1. Common Installation Procedures for All Hardware Options 1) Top Panel Removal Remove the top panel from the FA-1010. (Remove the 3 screws on the top panel, and 2 screws each from both side panels. Remove rack ears if attached.) * All removed screws (11 total) will be used to close the top panel.

  • Page 10: Installation Procedure For Each Option

    3-2. Installation Procedure for Each Option 3-2-1. FA-10AES-BL Nest connectors on the option card into the slot, align screw holes, then secure the card with the supplied double-SEMS screws. Connect the PWA cable (Fig. 6). Secure the option card to the rear panel with the binding screws removed under Common Installation/Removal Procedure.

  • Page 11: Fa-10Aes-Ublc

    Connect the PWA cable connector to CN9 (Fig. 8). Secure the option card to the rear panel with the binding screws removed in Common Installation/Removal Procedure. Connect FA-10AES-UBLC PWA connector 109 to CN9. FA-1010 MAIN CARD FA-10AES-UBLC FA-10AES-UBLC AES CARD...

  • Page 12: Fa-10Ana-Aud

    Common Installation/Removal Procedure. Connect PWA connector Keep the PWA cables away from the power unit. 121 to CN21. FA-1010 MAIN CARD SLOT D CN21 Fasten the PWA cables to the top of studs with blue fastening cords and 3x6 bind screws to keep the PWA away from the power unit.

  • Page 13: Fa-10Gpi

    3-2-5. FA-10GPI 1) Nest connectors on the option card into the slot, align screw holes, then lightly secure the card with the supplied double-SEMS screws. 2) Secure the option card to the rear panel with the binding screws removed in Common Installation/Removal Procedure.

  • Page 14: Fa-10Ps

    3-2-6. FA-10PS PWA1658-2 1) Attach the ferrite core to leads A and B of PWA1658-2. Wrap the white and black cables together around the ferrite core once. Cables should be bundles closely Within 40 mm together. 2) Connect leads A, B, and I (grounding terminal) of the cable to the AC inlet. 3) Connect C of the cable to the power switch.
  • Page 15 8) Connect connector E (numbered 401) of cable PWA1658-2 to CN 1 (3-pin) on the power supply unit. 9) Connect connector F (numbered 451) to CN 4 (8-pin). 10) Connect connector G (numbered 129) to CN 29 (6-pin) on the main card. 11) Fasten cables using the supplied cable ties and cable tie mounts as shown in the figure below.

  • Page 16: Fa-10Ps Verification

    Push switch 1 up. 3-2-6-1. FA-10PS Verification 1) Connect an AC cord to FA-1010 AC IN 1 and turn the power on. 2) Verify that the DC Power 2 LED on the front panel is lit red. 3) Connect another AC cord to AC IN 2 while the power is on, then verify that the DC Power 2 LED turns green.

  • Page 17: Fa-1010 Update

    6. Click [Update] to start updating. (Fig. 13 ④). The selected file needs to be in .ais format with a file name that begins with “FA1010_”. If an error occurs, verify that the data is FA-1010 software data. 7. A message appears when the update is complete.

  • Page 18: Fpga Update (Pm9221) (Required Time: 7 Minutes)

    6. Click [Update] to start updating (Fig. 14 ④). The selected file needs to be in .pof format with a file name that begins with “FA1010_”. If an error occurs, verify that the data is FA-1010 FPGA data. 7. A message appears when the update is complete.

  • Page 19: Cpld Update (Pm9223) (Required Time: 2 Min.)

    13. If [Progress] indicates 100% (Fig. 16 ⑨) and no error sign (in red) appears on the status bar at the bottom of the window (Fig. 16 ⑩), the update is complete. 14. Turn the power of the FA-1010 off, and disconnect the cable from CN24. 15. Close the top panel of the FA-1010.

  • Page 20: Fa-10Ru Update

    If an error occurs, verify that the data is FA-10RU software data. 7. A message appears when the update is complete. ① Enter the IP address ②Check FA-10RU Soft ③ Select the latest software data ④ Click Update Fig. 17 FA-1010 Program Updater dialog (for FA-10RU software update settings)

  • Page 21: Cpld Update (Pm9290,Pm9291) (Required Time: 2Min.)

    5-2. CPLD Update (PM9290,PM9291) (Required Time: 2min.) Updating CPLD1, 2 (PM9290, PM9291) 1. Remove the top panel of the FA-10RU. 2. Connect the ByteBlaster II to the parallel port of a PC (or USB Blaster cable to a USB port). 3.

  • Page 22: Fa-10Dccru Update

    8. After ensuring that the message “Please Reboot” is displayed on the front panel screen, reboot the unit. ② Enter the IP address ② Check FA-10DCCRU Soft ③ Select the latest software data ④ Click Update Fig. 19 FA-1010 Program Updater dialog (for FA-10DCCRU software update settings)

  • Page 23: Cpld Update (Pm9314, Pm9315) (Required Time: 3 Min.)

    6-2. CPLD Update (PM9314, PM9315) (Required Time: 3 min.) Updating CPLD1, 2 (PM9314, PM9315) 1. Remove the top panel of the FA-10DCCRU. 2. Connect the ByteBlaster II to the parallel port of a PC (or USB Blaster cable to a USB port). 3.

  • Page 24: Fa-10Aes-Bl/Ubl Update

    If an error occurs, verify that the data is FA-10AES FPGA data. 9. A message appears when the update is complete. 10. Turn the power of the FA-1010 on, and verify that the latest FPGA2 version is displayed in the FA-1010GUI Status tab.

  • Page 25: Cpld Update (Pm 9225) (Required Time: 30 Sec.)

    (Fig. 22 ⑩) 12. Turn the power of the FA-1010, and disconnect the cable from CN4. 13. Turn the power of the FA-1010 on, and verify that the latest FPGA1 version is displayed in the FA-1010GUI Status tab.

  • Page 26: Appendix A. Creating Fa-1010 Backup Data

    Event Name setting screen. Event Name (See Sec. A-1-1-1. “Event Name Edit”.) *1 See Sec. 9. “Menu List” of FA-1010 Operation Manual for details on the event loading in different modes. *2 Event names will be displayed for Event Load/Event Save settings.

  • Page 27: A-1-1-1. Event Name Edit

    Events 1 to 100 can be named in this page. A-1-2. Backup Parameter The FA-1010 settings can be saved to a file, and the saved settings in a file can be loaded.  Saving the FA-1010 Settings to a File Click Save.

  • Page 28: A-1-3. Event Data Backup

    Specify a destination directory, and click Open. Click Restore. A confirmation message as shown below opens. Click OK to start transferring file material to the FA-1010. To stop the file transfer, click Cancel. * Some parameters such as By-pass and Freeze settings are not stored in any Backup Parameter.
  • Page 29  Save File Click Save. A window as shown below opens. Specify a destination directory and file name, then click Save. A “Saving in progress” message box appears. Once the file has been saved, a “Saving complete” message box appears. ...

  • Page 30: Appendix B. Creating Fa-10Ru Backup Data

    Appendix B. Creating FA-10RU Backup Data B-1. Backup & Restore Clicking Backup & Restore opens the dialog box as shown below. This dialog box allows you to save the FA-10RU settings and event data to a PC. The saved data can be recalled.

  • Page 31: B-1-1. Configuration Data Backup

    B-1-1. Configuration Data Backup The FA-10RU configuration data can be saved/recalled to/from a PC as a CSV file.  Saving Configuration Data to a PC Click Save File: Save under “Backup Config Data”. Click Save to save the data to a desired folder. ...

  • Page 32: B-1-2. Event Data Backup

    B-1-2. Event Data Backup The event data saved in the FA-10RU can be saved/recalled to/from a PC.  Saving Configuration Data to a file Click Save File: Save under “Backup Event Data”. Click Save to save the data to the desired folder. ...

  • Page 33: Appendix C. Creating Fa-10Dccru Backup Data

    Appendix C. Creating FA-10DCCRU Backup Data C-1. Backup & Restore Click Backup & Restore in the left pane to display the Backup & Restore page. This page allows you to perform the following backup and restoration tasks.  Backup and restore Network Settings, Unit ID Assignment, Direct Mode Settings, and Event Name pages, and GPI and System settings.
  • Page 34 (1) Check on the checkboxes in the Config Data area to select data. (2) Click Browse to select the backup file. (3) Click Load. A confirmation dialog will appear. Click OK to load the settings. To cancel the process, click Cancel. IMPORTANT After loading network settings, restart the FA-10DCCRU.

  • Page 35: Appendix D. Verifying The Fa-1010 Version

    Appendix D. Verifying the FA-1010 Version D-1. Status (GUI) Click the Status tab at the top of the page to open the status page. * An exclamation mark ( ! ) is displayed on the Status tab, if an error occurs in a FAN or power supply unit.
  • Page 36  Fan Status Item Indication Description Displays the status of FAN 1-4 respectively. Normal: Operating normally. Normal FAN 1-4 Stopped: The FAN has stopped. Stopped Turn the unit power off, and contact your dealer for assistance.  Power Supply Status Item Indication Description...

  • Page 37: D-2. Status (Web)

    D-2. Status (Web) Clicking the Status tab on the menu bar opens the dropdown menu as shown below. D-2-1. Unit Status  FA-1010 Item Description Serial Number Displays the serial number of the unit. Software Displays the software version. FPGA 1- 5 Displays the version of each FPGA.

  • Page 38: Appendix E. Verifying The Fa-10Ru Version

    Item Description Status Displays the status of connection with FA-1010. Displays the registered ID number if the connected FA-1010 IP address is registered using Unit ID Assignment Unit ID Displays an ”IP Address Select” message, if the connection is established...

  • Page 39: Appendix F. Verifying The Fa-10Dccru Version

    Appendix F. Verifying the FA-10DCCRU Version F-1. SYSTEM Setting (Front Panel) Press and hold the GRP ADJ/SYSTEM button to enter System Setting mode. The GRP ADJ/SYSTEM button flashes in this mode. Pressing the flashing GRP ADJ/SYSTEM button exits System Setting mode and the button functions as a Group ADJ On/Off.

  • Page 40: F-1-1. System Settings

    Displays the FPGA2 version. (*1) See section 8-2. “GPI OUT LED Indicator Brightness Settings.” in the FA-10DCCRU Operation Manual. (*2) When the fan has stopped, turn off the unit power, notify your FOR-A reseller or supplier and change the fan.

  • Page 41: F-2. Information (Web)

    F-2. Information (Web) Click Information in the left pane to display the Information page, in which Unit Information and Connection Status details of the FA-10DCCRU are displayed.  FA-10DCCRU version, serial number and network setting details  Main Unit information Click Refresh to refresh the page.
