12-2-5-3. Dynamic Range Gain

Click Color Processor 1 or Color Processor 2 in the Video Block and select Dynamic Range
Gain to display the menu as shown below.
[Windows GUI]
[Web GUI] (Scrolling up and down to go through the page.)
Item Default
Simul Mode Disable
DR Gain 0.00dB
SDR Gain 0.00dB
Input / Gain / Output / Total
Setting
Sets whether to keep the gain difference
between FS 1 and 2.
Disable
If Enable is set and Dynamic Range Gain
Enable of FS1 is changed, Dynamic Range Gain
of FS2 is also changed with the same
difference.
Sets the RGB dynamic range gain in the
-24.00 to 24.00dB
linear scale space.
Sets the gain difference between SDR and
HDR. The total gain is equal to addition of
SDR Gain and DR Gain values. When
0.00 to 24.00dB
converting between SDR signals or
between HDR signals, this setting is
ignored.
Displays the gain difference between before
and after conversion.
159
