FOR-A FA-9600 Operation Manual page 237

Line (Min) mode
Converter 1
(FA-96UDC)
Supporter formats
Converter 2
(FA-96UDC)
Supporter formats
Frame delay
Color processing
Proc. Amp.
Color correction
Video clip
Gamut
EOTF/OETF
SDI audio input
SDI audio output
HDMI audio input
HDMI audio output
AES audio input
AES audio output
(W/ FA-96AES-UBL)
(W/ FA-96AES-UBLC)
Horizontal: -1/2 H to +1/2 H
Vertical: -1/2 frame to +1/2 frame
Delay: <Max> 1 H + 700 clk
4K 2SI/SQD conversion, Up-, Down-, Cross-conversions,
Aspect ratio conversions, Resizing, Re-positioning, I-P conversions, 3G-SDI
Level A/B conversions, Easy frame rate conversions
3840 x 2160/59.94p, 50p
3840 x 2160/60p, 48p, 47.95p, 30p, 29.97p, 25p, 24p, 23.98p
3840 x 2160/30PsF, 29.97PsF, 25PsF, 24PsF, 23.98PsF
1080/59.94p, 50p, 29.97p, 25p, 23.98p
1080/59.94i, 50i, 23.98PsF
1080/60p, 30p, 24p
1080/60i, 30PsF, 29.97PsF, 25PsF, 24PsF
720/59.94p, 50p
720/60p, 30p, 29.97p, 25p, 24p, 23.98p
525/59.94i, 625/50i
I-P conversions
3G-SDI Level A/B conversions,
Easy frame rate conversions
(Up- / down- / cross-conversion, aspect conversion, resizing, position
change: Dual HD mode (MU Main mode) only)
1080/59.94p, 50p, 29.97p, 25p
1080/60p, 30p, 24p
1080/59.94i, 50i
1080/60i, 30PsF, 29.97PsF, 25PsF, 24PsF
720/60p, 30p, 29.97p, 25p, 24p, 23.98p
Max. 8 frames
Proc. Amp, Color space conversion, EOTF (de-gamma) / OETF (gamma)
Color corrector, Video clip
Video level: 0.0% to 200.0%
Chroma level: 0.0% to 200.0%
Black level: -20.0% to 100.0%
Hue: -179.8° to +180°
Balance (RGB) mode
Differential (YCbCr) mode
Knee Clip (RGB), YCbCr Clip
ITU-R BT.709/2020, User defined gamut (Data unloadable)
HLG, SMPTE2048, ITU-R BT.1886, User defined functions (Data loadable)
12G/6G/3G/HD-SDI: 16 channels (Group 1-4)
48 kHz 16- to 24-bit Synchronous / Asynchronous audio
SD-SDI: 16 channels (Group 1-4)
48 kHz 16- to 24-bit Synchronous audio
12G/6G/3G/HD-SDI: 16 channels (Group 1-4)
48 kHz 16/20/24-bit Synchronous / Asynchronous audio
SD-SDI: 12 channels (Group 1-3)
48 kHz 16-/20-/24-bit Synchronous audio
8 channels 48kHz 16- to 24-bit synchronous
8 channels 48kHz 16/20/24-bit synchronous
1.0 Vp-p unbalanced 75Ω 32/44.1/48 kHz 16- to 24-bit
1.0 Vp-p unbalanced 75Ω 48 kHz 16/20/24-bit
BNC x 8 (AES/EBU input or output) 16 channels (8 stereo pairs)
BNC x 4 (AES/EBU input) 8 channels (4 stereo pairs)
BNC x 4 (AES/EBU output) 8 channels (4 stereo pairs)
237
<Min> 700 clk
