OPERATION
MANUAL
USF-1043FS
Frame Synchronizer
st
1
Edition - Rev. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USF-1043FS and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A USF-1043FS

Summary of Contents for FOR-A USF-1043FS

  • Page 1 OPERATION MANUAL USF-1043FS Frame Synchronizer Edition - Rev. 2...

  • Page 2: Important Safety Warnings

    Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check the power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
  • Page 3 Upon Receipt Unpacking USF-1043FS units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing list below. Check to ensure no damage has occurred during shipment.

  • Page 4: Table Of Contents

    2. Panel Descriptions ..........................7 2-1. Front Panel ..........................7 2-2. Rear Panel ..........................7 3. Connection ............................8 3-1. USF-1043FS Connection Example ..................... 8 4. WEB GUI .............................. 9 4-1. Video Process ..........................9 4-1-1. Video Process Amplifier .....................10 4-1-2.
  • Page 5 9-2. External Dimensions .........................35...

  • Page 6: Prior To Starting

    1-1. Overview The USF-1043FS is a plug-in module to be mounted into a USF-212S frame. The USF-1043FS has been developed as a frame / line synchronizer that supports 3G / HD / SD-SDI taking full advantage of the latest digital technologies.

  • Page 7: Panel Descriptions

    2. Panel Descriptions 2-1. Front Panel USF-1043FS Name Description OPERATE LED Lights when the power is supplied from USF frame. On: A genlock signal is present. GENLOCK LED Off: No genlock signal is present. 2-2. Rear Panel 3G/HD/SD SDI OUT...

  • Page 8: Connection

    To be connected with devices that can accept SDI signals. (*1) Select a genlock signal used in USF-1043FS. (Refer to Sec. 4-2-1. “System Settings”) (*2) Input the same signal into SDI IN 1 and 2, if using USF-1043FS changeover function.

  • Page 9: Web Gui

    4. WEB GUI Start the web browser on the PC and connect to USF-1043FS installed in the USF-212S frame. The following window will open. Refer to the USF-212S operation manual for how to connect to USF-1043FS from the web browser.

  • Page 10: Video Process Amplifier

    SDI 1 Changeover as Disable to select a video Primary SDI 2 signal. SDI 1 Source Slot XX (XX is slot number) Rear Input: Selects the input signal from SDI 1 or SDI 2 on the rear side of USF-1043FS.
  • Page 11 (XX is slot number) Frame Interconnect: The slot number changes according to the slot number in which the USF-1043FS is installed. Refer to ”Frame Interconnect Slot Display List” for the slot number to be displayed. Selects a video signal to be processed in Primary USF-1043FS.
  • Page 12 to an input signal. Delay is settable with System Phase and Frame Delay. Minimum delay is (3G Level-A: 500clk/3G Level-B: 520clk/HD: 500clk/SD: 700clk) （Unit – HD: 74MHz, SD27MHz） Genlock signal is not used. Genlock 1 Reference Genlock Selects a reference signal supplied by the Select frame.

  • Page 13: Compatibility List Of Reference And Sdi Signal Formats

    Slot10, Slot11, Slot12 Slot9, Slot11, Slot12 Slot9, Slot10, Slot12 Slot9, Slot10, Slot11 USF-1043FS can send and receive video signals from any slot in the same vertical line on the USF frame. 4-2-1-1. Compatibility List of Reference and SDI Signal Formats 1080 Sync.

  • Page 14: System Phase/Video Position

    4-2-2. System Phase/Video Position Refresh: Updates the screen into the latest. Unity: Resets a parameter to default value. Clicking ＋ increases the setting by a minimum step. Clicking － decreases the setting by a minimum step. The settings can be changed by using a slider or by inputting a value directly into the white box.

  • Page 15: Video Freeze

    -1100 to +1100 (1) 1080/50p -1320 to +1320 (1) 720/59.94p -825 to +825 (1) -375 to +375 (1) 720/50p -990 to +990 (1)  USF-1043FS Delay List Delay Format Line AVDL Input 525/60, 625/50 700 clk 1080/59.94i, 1080/50i 500 clk 1080/24PsF, 1080/23.98PsF...

  • Page 16: Audio Sampling Rate Converter Settings

    4-3. Audio Sampling Rate Converter Settings Navigate to the SRC window by clicking Audio, then SRC. Item Default Choice Description Sets the SRC circuit to pass or by-pass audio signals per channel pair. Auto: Sets the SRC circuit to pass signals. However, NON-PCM audio signals will be by-passed the SRC circuit automatically.

  • Page 17: Downmix Settings

    4-5. Downmix Settings Navigate to the Downmix Settings window by clicking Audio, then Downmix. 4-5-1. Bus Assign Allows you to set the downmix sound processing mode and sound channels. Item Default Choice Descriptions Stereo Mode Stereo Surround Sets the downmixing mode. Monaural Left SRC Ch.1...
  • Page 18 (*1) When Master Level is set to Auto, Audio Level changes as shown in the following table. Surround Mix Level -3dB -6dB -9dB 0 (-∞dB) Downmix Mode Stereo approx.-7.7dB approx.-6.9dB approx.-6.3dB approx.-4.6dB Surround approx.-9.9dB approx.-8.7dB approx.-7.7dB approx.-4.6dB Monaural approx.-12.9dB approx.-12.0dB approx.-11.4dB approx.-9.5dB ...

  • Page 19: Audio Remapping

    4-6. Audio Remapping Navigate to the Audio Remapping widow by clicking Audio, then Remapping. Allows you to set audio remapping. Item Default Choice Descriptions SRC Ch.1 to 16 Assigns audio signals to Audio output Ch.1 Silence SRC Ch.1 to Ch.16. 500Hz Tone Ch.1 to 16 Selects Downmix L and Downmix R for...

  • Page 20: Audio Gain

    4-8. Audio Gain Navigate to the Audio Gain window by clicking Audio, then Gain. Refresh: Updates the screen into the latest. Unity: Resets a parameter to default value. Clicking ＋ increases the setting by a minimum step. Clicking － decreases the setting by a minimum step. The settings can be changed by using a slider or by inputting a value directly into the white box.

  • Page 21: Audio System

    Item Default Setting range Description Master 5ms to 1000ms Sets the Delay offset for all channels (1 -16). Ch.1-16 5ms to 1000ms Sets the Delay for each channel (1 -16). 4-10. Audio System Navigate to the Audio System window by clicking Navigate, then System. 4-10-1.
  • Page 22 Set to Disable for a specific program or duration when audio output has noise or is muted. The USF-1043FS fades out audio or resets the delay circuit when a status change (SDI signal input interruption, signal switchover (by a router, etc.)) is detected. Faulty ancillary data in normal audio signals may also be detected as status changes.

  • Page 23: Embedded Settings

    4-10-2. Embedded Settings Item Default Choice Description Selects whether to embed audio into the SDI stream per audio group. Group 1 to 4 Disable Enable Embedded Enable Disable: Audio data not to be embedded. Enable: Audio data to be embedded. Auto Auto: Automatically selects audio clock Group 1...

  • Page 24: Module Information

    Displays the SDI signal format input from a frame bus. From Slot * The displayed Slot number differs according to the slot in which the USF-1043FS is installed. Refer to “Frame Interconnect Slot Display List Current Source Displays the signal format set for Primary Source in Video System.

  • Page 25: Audio Status

    Load Default Event1 to 10 When Default is loaded, only the parameters returns to their default settings. Saves an event to the USF-1043FS. Select an Save Event1 to 10 Event1 to 10 event from pulldown menu and click Save. * Trap settings are not included in Event Settings / Savings.

  • Page 26: Import / Export

    4-14-2. Import / Export USF-1043FS settings can be saved as .dat files on a PC and also loaded into USF-1043FS from the saved data.  Saving parameters Clicking the Export button under the Parameter area saves Video/Audio/Trap parameters on the PC in .dat format.

  • Page 27: Trap Settings

    4-15. Trap Settings Navigate to the Trap Settings window by clicking Trap. To enable traps to be sent to the SNMP manager from USF-1043FS when any changes occur, select Enable. Selecting Disable stops traps from being sent even if a change occurs.

  • Page 28: Downloading The Mib (Management Information Base) File

    MIB (Management Information Base) for your SNMP manager. (2) Select Save (S) from the opened dialog box. (3) FORA-USF-1043FS-MIB.zip File is downloaded. (4) Unzip the file and load it into your SNMP manager. NOTE SNMP community names and trap destination IP addresses are set in the USF-212S frame.

  • Page 29: About Snmp

    5. About SNMP The USF-1043FS can be remotely monitored using an external SNMP monitoring system that supports SNMPv2C. MIB（Management Information Base） files required for the SNMP monitoring system can be downloaded from Web GUI. Refer to Sec. 4-15-3. “Downloading the MIB (Management Information Base) File”...
  • Page 30  usf1043FsEmbedIn2 INTEGER  usf1043FsEmbedIn3 INTEGER  usf1043FsEmbedIn4 INTEGER  usf1043FsEmbedIn5 INTEGER  usf1043FsEmbedIn6 INTEGER  usf1043FsEmbedIn7 INTEGER  usf1043FsEmbedIn8 INTEGER  usf1043FsEmbedIn9 Same as above INTEGER  usf1043FsEmbedIn10 INTEGER  usf1043FsEmbedIn11 INTEGER  usf1043FsEmbedIn12 INTEGER  usf1043FsEmbedIn13 INTEGER  usf1043FsEmbedIn14 INTEGER ...

  • Page 31: Block Diagram

    6. Block Diagram 6-1. VIDEO FS/LS & Frame delay Primary channel & SDI 1 Freeze Proc.Amp (automatic) & position Video Loss Back Color FS/LS & Frame delay & SEL 2:1 SDI 1-4 Freeze SDI 2 & position Test signal Color Bar Number Settings Outline Video Display Settings...

  • Page 32: Internal Settings

    7. Internal Settings The USF-1043FS module initialization can be executed by setting front module DIP switch (DS1).  DS1 Settings Number Functions Factory Setting Setting not changeable Setting not changeable Setting not changeable Setting not changeable Setting not changeable Initialize into factory setting...

  • Page 33: Troubleshooting

    8. Troubleshooting If any of the following problems occur while operating your USF-1043FS, proceed as indicated below to see if the problem can be corrected before assuming a unit malfunction has occurred. Problem Check Action The picture stops. Is Video Freeze On? Turn Off the Video Freeze.

  • Page 34: Specifications And Dimensions

    9. Specifications and Dimensions 9-1. Unit Specifications Video formats 3G: 1080/59.94p, 50p (Level-A/B) HD: 1080/59.94i, 50i, 720/59.94p, 50p, 1080/23.98PsF, 1080/24PsF SD: 525/60, 625/50 Video input 3G-SDI: 3 Gbps, HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75Ω BNC x 2 Video output 3G-SDI: 3 Gbps, HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75Ω...

  • Page 35: External Dimensions

    Audio functions SRC (Sample Rate Converter), gain control, remapping, mute (per channel) downmix Remote control Web control / SNMP control (require USF-212S) Temperature 0ºC to 40 ºC0 Humidity 30% to 90% (no condensation) Power +12V DC (Supplied by USF frame) Power consumption 0.8A 20W Dimensions...
