FOR-A FA-9600 Operation Manual page 144

Item
FS1 Converter
Synchronizer
Source Select
(Converter 1 only)
Format Convert
◆
I/P Convert
Item Default
Motion
Adaptive
Sense
The following parameters are enabled when Format Convert is set to Manual.
Refer to "Appendix 1: Video Format Conversions" for more details.
◆
Output Format
Item Default
Standard 1080
Horizontal -
Frame
59.94i
Rate
Level Level-A
Division
(UHD) 2SI
(FA-964K)
Default Setting
Synchronizer 1
1
Synchronizer 2
Follow Input
Follow Input
Manual
Setting
Field: Generates a progressive image from one field of
an interlaced image. The created image has no motion
artifacts, but vertical resolution will be reduced.
Adaptive
Adaptive: Detects whether there is motion or no
Field motion in the scene, and generates an optimal
progressive image.
Frame
(Odd 1st) Frame(Odd 1st): Generates a progressive image from
two fields (odd and even) of an interlaced image.
Frame
Suitable for progressive segmented frame input shot in
(Even 1st)
progressive format.
Frame(Even 1st): Generates a progressive image
from two fields (even and odd) of and interlaced image.
Setting
SD
720
1080
2160
-
60p, 59.94p, 50p, 48p, 47.95p
30p, 29.97p, 25p, 24p, 23.98p
60i, 59.94i, 50i
24PsF, 23.98PsF,
30PsF, 29.97PsF, 25PsF
Level-A
Level-B
SQD
2SI
144
Description
Selects a Converter1 input
source. (Simultaneous 4K/HD
mode only)
Specifies the converter output
format.
Follow Input: Converter input
signal format
Manual: Signal format specified
below.
Description
Description
Specifies the vertical image
resolution. (2160 available only
on FS1 in Simultaneous 4K/HD
or 3D-LUT mode with FA-964K.)
Fixed
(Not displayed in Web GUI)
Specifies the frame/field rate.
Selects the SDI mapping level.
Selects the SDI image division
method when 2160 is selected
under Standard.
