FOR-A FA-9600 Operation Manual page 168

◆
Vertical Ancillary Multiplex
Item Default
Mode Pass
Set the following parameters if Mode is set to Rewrite.
ARIB
Disable
STD-B37
ARIB
Disable
STD-B39
User
Packet
Disable
(Support
planned)
Set the following parameters if ARIB STD-B39 is set to Overwrite.
Audio
Pass
Method
Audio
Mode Unused
Data
◆
User Packet Line Select (Planned for future support)
Press the Line Select button to display the dialog box. (Windows GUI only)
Item
SD (525/59.94i)
SD (625/50i)
720p
1080i/PsF/2160PsF
1080p/2160p(1.5G)
1080p/2160p(3G-A)
1080p/2160p(3G-B)
Setting
Selects the VANC data insertion mode.
Pass: Passes through the input VANC data without
processing. If input and output signal formats are
different, the VANC space becomes blank. If the SDI
input and reference are not synchronized, packet loss
Pass or duplication may occur due to timing adjustment.
Rewrite
Rewrite: Outputs black in the VANC area. If ARIB
STD-B37, STD-B39 and/or User Packet are set to
other than Disable in the ANC DATA INSERTION
menu (See Sec. 5-34.) and the packet is included in
input signal, it is inserted in the proper space on the
output signal.
Disable Disable: Inserts no data packets.
Through
Through: Extracts packets from the SDI input and
inserts them into the appropriate place of the SDI
Disable
output without change. The inserted line varies by
Through
signal format. If the SDI input and reference are not
Overwrite
synchronized, packet loss or duplication may occur
due to timing adjustment.
Overwrite: Inserts the internally generated (Audio
Mode) control signal packets defined by ARIB STD-
B39. Audio data information to be inserted should be
Disable
set under Audio Method and Audio Mode Data below.
Through
Other information in the input signal (except Audio
Mode) is used for output.
See Sec. 5-34. "ANC DATA INSERTION" for more
details.
Pass: Passes the input signal ARIB STD-B39 Audio
Mode data through to the output or overwrites the
new information if input and output audio formats are
Pass
different.
Overwrite
Overwrite: Replaces the audio information to the one
set under Mode Data if ARIB STD-B39 Audio Mode
data is inserted in the input signal.
Selects the Audio Mode data from the table in Sec. 6-
-
4.
Default
Line 17/280 Line 12/275 - 19/282
Line 17/330 Line 8/321 - 22/335
Line 17 Line 9 - 25
Line 17/579 Line 9/571 - 20/582
Line 17 Line 9 - 41
Line 17 Line 9 - 41
Line 17/579 Line 9/571 - 20/582
168
Description
Setting
Selects the line
number into which
the user packet is
inserted under the
output format.
Description
