7-19. AES / ANALOG AUDIO OUT STATUS

Item
Ch.1/2
Ch.3/4
Ch.5/6
Non-PCM, Non-PCM (Async)
Ch.7/8
Ch.1/2
Ch.3/4

7-20. MADI AUDIO OUTPUT STATUS

|
Item
Signal
Ch.1/2 to Ch.63/64
Display
PCM, PCM (Async)
Mute, Mute (Async)
Dolby E, Dolby E (Async)
Input Setting
Mute
Present
Display
Output Disable
Input Through
Present (48kHz, 56Ch)
Present (48kHz, 64Ch)
Output Disable
PCM
Mute
121
* If FA-96AES-UBLC is installed,
"(UBLC)" is displayed in the menu
title, since UBLC has become the
standard output of AES audio.
Required FA-96AES-UBL
option
Required FA-96ANA-AUD
option
Description
Displays each channel status of AES
outputs.
Input Settings is displayed if AES ports
are set to input.
Displays analog audio channel output
status.
Required FA-96MADI
option
Description
Displays the MADI audio output signal
status.
Displays each audio channel status of
MADI output.
