Information in this Display
Packets In/Out
Bytes In/Out
Multi-Cast In/Out
Broadcast In/Out
Frm Dropped In/Out
Q Dropped In
Dropped Timeout
Errors In
Ethernet-Specific Statistics
Alignment Errors
Xmt w/1 Coll
Overrun Errors
Xmt w/mul Coll
Xmt/Deferral
Xmt CD Heartbeat
Not Xmt (Coll)
Frm w/lost CS
Late Collisions
3-30
is the number of packets received/transmitted over the
interface.
is the number of bytes received/transmitted over the
interface.
is the number of packets received/transmitted via a multicast
address over the interface.
is the number of packets received/transmitted via a broadcast
address over the interface.
is the number of incoming/outgoing frames that were
dropped.
is the number of incoming Q-packets that were dropped.
is the number of transmitted frames that did not return due to
a timeout or reception of another frame.
is the number of errors received over the interface.
is the number of frames with FCS (frame check sequence)
errors due to non-integral lengths.
is the number of frames that were transmitted after one col-
lision (with a frame transmitted from another node).
is the number of frames that were not accepted due to DMA
(direct memory access) overrun errors.
is the number of frames that were transmitted after multiple
collisions.
is the number of frames that were held up due to traffic from
other directions, then transmitted later.
is the number of frames that were transmitted containing a CD
(collision detection) signal.
is the number of frames that were not transmitted due to
collisions.
is the number of frames that experienced a loss of the CS
(carrier sense) signal at the receiving node.
is the number of transmitted frames that were involved in
collisions while outside the flow control window.
FRX8000 Installation & Setup Guide
