The following figure shows an example of a display for an X.25 port.
09:23:05:16R
09:23:05:27R
09:23:05:27R
09:23:06:05T
09:23:06:18T
09:23:07:13T
Information in This Display
On each line (see CCITT Recommendation X.25):
The leftmost field shows the time, to hundredths of a second.
The next field displays
are also displayed in reverse video.)
The next field identifies the packet type.
, or appears between the packet type and the LCN field if the Q, M, or D
M D
bit is turned on in the packet.
is the logical channel of a data session.
LCN
is the packet receive sequence number.
PR
is the packet send sequence number.
PS
is the length of the data in bytes.
LNG
The field to the right of the colon contains the data in a data packet. (Data
exceeding the screen width is displayed on the next line.)
3-10
DATA LC N 4072 PR 4 PS 4LNG 1024 :56686520756190G801
DATA LC N 4072 PR 4 PS 5LNG 1024 :46686521255190G811
RR LC N 4071 PR 6 PS
RR LC N 4072 PR 6 PS
DATA LC N 4072 PR 6 PS 6LNG 1024 :557586707555090G85
DATA LC N 4071 PR 6 PS 7LNG 1024 :54389450758090G859
Figure 3-7 Line Monitor Display
(Transmit) or
T
[A],[E] from FRX8000 Test Menu
(Receive). (Transmitted packets
R
