Power Switch
COM2
Power
Cable
Connector
The VGA adapter in the Rackmount node is a daughter card mounted on
the CPU card, which also contains COM1, COM2, and LPT1. The VGA
and COM2 ports are connected via cables.
Power Cable
Connector
Figure 2-4 High-Availability Node, Rear View
Although it appears from the rear that this model has 18 card slots, the
motherboard actually has 13. A fan occupies the left five openings, and
the disk controller occupies the next two.
Installing a Node
VGA Port
LPT1
Keyboard Connector
Voltage
Selection Switch
Figure 2-3 Rackmount Node, Rear View
VGA Port
RLPs
COM1
RLPs
LAN Adapter
LAN Card
LAN Card
RLPs
Keyboard
COM1
LPT1
COM2
Connector
RLPs
2- 5
