Figure 2-6

shows the typical cabling. For guidance in placing equipment, standard

cable lengths are:

Power cables = 6 feet

Monitor to node cable = 4 feet

Keyboard cables (unstretched) = 1.5 feet

RLP to I/O box cable = 6 feet

I/O cables = 5 feet

Auxiliary Console cables = 5 feet

Installing a Node

2- 7
