Pressing
parameters.
5. When the port is configured the way you want it, press
uration Menu
again at the Node Configuration Menu
6. Connect all trunk cables from the node.
The remainder of this procedure is performed at an INM in the opera-
tional network.
7. At an INM in the operational network, press
Main Menu to display a menu of Boot Disk Download Operations.
8. Press
[A]
9. When prompted, enter the ID of the new node.
10. When a message informs you that the operation is complete, press any key.
This will display the Boot Disk Download Operations Menu.
11. Press . This will display the Node Operations Menu.
[R]
12. Press
[B]
This completes installation of the FRX8000. If the monitor and keyboard were left
attached, the FRX8000 Test Menu (Figure 2-12) will be displayed after the node
boots.
If an Intel® Token Ring card is installed, a ring speed of 16 Mbps was selected
during software configuration. If you want to change the ring speed, go to
figuring a Token Ring LAN
The node does not need the attached monitor and keyboard for normal
operation; however, they can be useful for displaying local status and
statistics.
Installing a Node
at the screen in Figure 2-11 will display a screen of logical
[P]
(Figure 2-8 [physical trunk] or
to select
Configuration Update
to re-IPL the new node. When prompted, enter the node ID.
Adapter" on page 2-39.
at the Port Config-
[R]
Figure 2-9 [logical trunk]), then
(Figure 2-7).
, then , then
[B] [B]
.
from the
[D]
"Re-con-
2- 15
