Pkts Delivered
Bad Hdr Length
Local Pkts Sent
Bad Pkt Length
Pkts Dropped
Pkt Fragments
Total Reasmbled
Frag Time Out
Pkts Fragmented
Frag Dropped
Frag Created
Pkts Forwarded
Can't Frag

ICMP Statistics

ICMP statistics track traffic of Internet Control Message Protocol messages
through the node. (ICMP messages are encapsulated with IP headers and trans-
mitted with the IP traffic.) Press
3-18
the IP header would not fit into a single buffer.
is the number of datagrams delivered to an application
(e.g., SNMP) on this node).
is the number of datagrams received with a header size less than
the minimum IP header length.
is the number of datagrams generated/forwarded by this node.
is the number of datagrams received with a length shorter than the
length of the header.
is the number of datagrams dropped due to a situation such as lack
of buffers.
is the number of datagram fragments received.
is the number of complete datagrams properly reassembled at this
node.
is the number of datagram fragments discarded because of
timeouts.
is the number of outgoing datagrams properly fragmented.
is the number of datagram fragments dropped because of
duplication or lack of space.
is the number of outgoing datagram fragments created.
is the number of datagrams forwarded.
is the number of times fragmentation of an datagram was
disallowed because the flag field did not allow fragmentation.
at the IP Statistics menu.
