Installation Procedures

Set Up the Hardware

This section applies to all device types.
1. Unpack and inspect the equipment. If there is evidence of physical damage,
contact the shipper. If parts are missing, contact Cabletron Systems Technical
Support or your distributor.
Cabletron Systems Technical Support can be reached at:
Phone:
FAX:
E-mail:
2. Each LP must have a unique ID within a device. LP IDs are determined by
dipswitches 1–3 on the card, as shown in
type of LP currently supported) will already be configured to be numbered
sequentially, beginning with 0. Numbering does not have to be sequential or
start with 0. The only requirements are that LPs be numbered within the range
0–7, and that each LP ID be different. Verify and change (if desired) the LP
IDs. Use a small screwdriver, pen, etc. to change switches. Do not use an
object that may break and drop pieces into the unit.
2-2
603-332-9400
603-337-3075
support@ctron.com
Figure 2-1. Any installed RLPs (the
FRX8000 Installation & Setup Guide
