Auto-answer
Modem
Auto-answer
Modem
Trunk
Network
Trunk
The Auxiliary Console can also connect directly to an INM via an
optional Cabletron cable.
2-8
Auxiliary Console (option)
Serial Printer
INM
RS-232 Cable
RLP Cable
I/O Box
FRX8000 Switch
Figure 2-6 FRX8000 Cabling Example
VGA
Monitor
Interface Cable to
Subscriber Device
Optional
VGA Monitor
Interface Cable to Modem
or Subscriber Device
