1.2 ecom-EN3-F, Transport variant professional case

1
2
3
4
5
6
7
Holding clamp for
1
the probe
Connection
4
Pressure
Connection USB
7
Condensation trap
10
(with Peltier cooler)
with fine dust filter
Connection air
13
temperature
ecom-EN3
Battery and sensors
2
compartment
Connections for Pa
5
pressure sensor
Integral thermal printer
8
Connection draught
11
Connection AUX
14
Graphic display
3
Slot for multi-media
6
card (SD)
Connection sampled gas
9
Connection gas
12
temperature
8
9
10
11
12
13
14
Page 9
