11.2.2 Connector supply voltage and DEBUG-interface

Pin assignment X2 (4-pole screw-plug connector, on the bottom side, at the back)
Pin No. Name
1 UB (Pwr)
2 0 V (Pwr)
3 Rx-Debug
4 Tx-Debug
Attention:
At isolated devices (option GT) Ground for the DEBUG-Interface must be
connected with pin 3 (AP-GND) of the RS-interface!
At devices that are not isolated also the 0V (Pwr)-signal can be used as
reference.

11.2.3 DeviceNet-connector

The plug (labeled: DeviceNet) for the connection to DeviceNet is available on the lower side of
the device.
Pin assignment X3 (5-pole screw-plug connector)
Pin No. Name
1 V-
2 CAN-L
3 Shield
4 CAN-H
5 V+

11.2.4 Power supply

The device must be powered with 10-33 VDC, The voltage supply is made through the 4-pole
screw-plug connector at the device's bottom side.
Please note that the devices of the series UNIGATE

11.3 LEDs

The Gateway UNIGATE
LED (Bus) Power
LED (Bus) State
LED Power
LED State
LEDs 1 / 2 / 4 / 8 (Error No. / Select ID) green

11.3.1 LED "(Bus) Power"

This LED is connected directly to the electrically isolated supply voltage of the DeviceNet-side.

11.3.2 LED "(Bus) State"

This LED operates as combined "Module/Network Status LED" according to DeviceNet-Specifi-
cation.
Lights green
Blinks green
Blinks red
Lights red
Blinks red/green
29.6.20 UNIGATE
®
CL - DeviceNet features 8 LEDs with the following significance:
green
red/green
green
red/green
Gateway connected to master
No connection to DeviceNet-master
Errors that can be removed (e. g. Timeout)
Serious error (e. g. double MAC-ID)
Communication error
®
fieldbus gateway UNIGATE
Hardware ports, switches and LEDs
Function
10..33 V supply voltage / DC
0 V supply voltage / DC
Receive signal Debug
Transmit signal Debug
Function
Supply voltage DeviceNet 0 V
Dominant Low
Cable shield
Dominant High
Supply voltage DeviceNet 24 V
®
should not be operated with AC voltage.
Supply voltage DeviceNet
Interface state DeviceNet
Supply voltage serial interface
User-defined / general Gateway error
User-defined / general Gateway error
®
CL - DeviceNet V. 2.8 43
™
