5. A list of drivers that can be installed on your server is presented. The
highlighted drivers represent detected systems that are installed by
default. If you have previously installed the Smart Array 221 Controller
board in this server the Compaq SCSI Controllers Support -
Install/Remove option is highlighted.
If you have not previously installed the Smart Array 221 Controller
board in this server you can still install the Smart Array 221 Controller
driver. The driver will appear on the list but will not be highlighted.
Highlight the driver.
6. After highlighting all the drivers you wish to install, select Continue.
Setup installs the selected drivers or prompts you for more information
to install, remove, or update a driver.
7. Select Continue. In the SCSI Adapter Setup window, select Add. A
Setup dialog box is displayed asking you to confirm the addition of a
SCSI controller (adapter). Select OK.
8. Scroll through the Adapter list and select Other.
When prompted for the path to the SCSI Adapter files, enter:
a:\scsi\array
Select Continue.
9. Select Compaq Drive Array from the list of drivers to install.
Select OK.
10. After the driver has been copied to the system, Setup returns to the SCSI
Adapter Setup dialog box. Compaq Drive Array should appear in the list
of installed SCSI controllers. Select Close.
11. Exit the program.
12. Remove the Compaq SSD for Windows NT from the drive, shut down
Windows NT, and reboot the server to load the driver.
