Page 64 of 220 Installing the hardware
Figure 27: Option 11 Meridian Companion card configuration—Expansion cabinet
NTAK04
AC/DC or
NTAK05 DC
power supply
11
12
13
14
15
16
17
18
19
20
Pwr Sup
CMRCs/CMLCs/CMBCs
553-3601-200 Standard 7.00 November 1998
