Northern Telecom Meridian SL-1 Reference Manual

2-mb/s digital trunk interface fault clearing procedures
Hide thumbs Also See for Meridian SL-1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, Installation Manual
SL-1
2-Mb/s Digital Trunk Interface
Fault clearing procedures
Publication number: 553-2911-510
Product release: Group F
Document status: Standard
Date: 91 03 08
© 1988 Northern Telecom
All right reserved
NT, Meridian 1, Meridian and SL-1 are trademarks of Northern Telecom.
Title to and ownership of SL-1 software shall at all times remain with Northern Telecom. SL-1 software
shall not be sold outright and the use thereof by the customer shall be subject to the parties entering into
agreement as specified by Northern Telecom.
Information contained in this document is subject to change. Northern Telecom reserves the right,
without notice, to make changes in equipment or program components as progress in engineering,
manufacturing, or technology may warrant.
2 Mb/s DTI Fault Clearing Procedures 553-2911-510

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Meridian SL-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Telecom Meridian SL-1

Summary of Contents for Northern Telecom Meridian SL-1

  • Page 1 SL-1 2-Mb/s Digital Trunk Interface Fault clearing procedures Publication number: 553-2911-510 Product release: Group F Document status: Standard Date: 91 03 08 © 1988 Northern Telecom All right reserved NT, Meridian 1, Meridian and SL-1 are trademarks of Northern Telecom. Title to and ownership of SL-1 software shall at all times remain with Northern Telecom.

  • Page 2: Reason For Revision

    Reason for revision 91 03 08 This procedure was reissued to include information on the Japan Digital Multiplex Interface (JDMI) for GenericX11 including supplementary features. It has been reformatted for CD-ROM application 553-2911-510 2 Mb/s DTI Fault Clearing Procedures...

  • Page 3: Table Of Contents

    Contents General Flowchart symbols Trouble analyzing procedures Alarm Lamps (LEDS) Out of Service (OOS) Alarm LED Lit Far-end Alarm (FEA) LED Lit Near-end Alarm (NEA) LED Lit Loopback Alarm LED Lit Disable (DIS) Alarm LED Lit Violation Error Messages Slip Error Message Frame Alignment Error Message DTI2/DMI Pack Replacement Clock Controller pack replacement...

  • Page 4: General

    General This manual describes the maintenance procedures for the Meridian SL- 2 Mb/s Digital Trunk Interface (DTI) and Japan Digital Multiplex Interface (JDMI) for GenericX11 including supplementary features. This manual is divided into two chapters. The first chapter contains step- by-step instructions on how to analyze a trouble.
  • Page 5 1-2 General Figure 1-1 (continued) Flowchart symbols Decision block - contains a question. The answer indicates the path to follow. Continuation symbol - contains the location of the next step Stop symbol - identifies the end of a procedure 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Answer this question.
  • Page 6 Figure 1-1 (continued) Flowchart symbols AND symbol - groups a sequence of steps, ALL of which must be performed to achieve a result. Perform this ( 1 ) step, and Perform this ( 2 ) step. OR symbol - groups a sequence of steps, only ONE of which must be performed to achieve a result.

  • Page 7: Trouble Analyzing Procedures

    Trouble analyzing procedures Alarm Lamps (LEDS) This section contains detailed step-by-step instructions on how to analyse a trouble (with reference to Detailed Procedures, where required) Out of Service (OOS) Alarm LED Lit If either the Near-end alarm (NEA) or Far-end alarm (FEA) LED is also lit, then perform that procedure (i.e., NEA or FEA) before attempting this procedure.
  • Page 8 2 - 2 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 status. Is the DTI2 pack out of service due to error counts being exceeded? Disable the DTI2 pack. Run DTI2 self test. (Chart 3-4) Is the OOS LED out? Unseat the DTI2 pack.

  • Page 9: Far-End Alarm (Fea) Led Lit

    Far-end Alarm (FEA) LED Lit DTI2 far-end alarm LED is lit. Load overlay 60. Check the DTI2 pack status, then disable the DTI2 pack and run DTI2 self test (Chart 3–4). Is the DT12 pack Disable the DTI2 pack and connect the loopback plug to the DTI2 faceplate (Chart 3–3).
  • Page 10 2 - 4 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Does the FEA LED remain out? Disable the DTI2 pack. At the Office Repeater Bay or the main cross connect terminal, loopback the 2 Mb/s signal to the DTI2. Enable the DTI2 pack.
  • Page 11 Is signal present? Connect line monitor to the Receive pair test jack (Rx-D) at Office Repeater Bay or Multiplexer. Is signal present? Restore cabling to normal. The problemis most likely with Receive cabling between the Office Repeater Bay and the DTI2 pack.

  • Page 12: Near-End Alarm (Nea) Led Lit

    2 - 6 Trouble analyzing procedures Near-end Alarm (NEA) LED Lit DTI2 near-end alarm LED is lit Load overlay 60. Check the DTI2 pack status, then disable the pack and check the error counts. Are any of the error thresholds exceeded? Disable the DTI2 pack and run DTI2 self test (Chart 3-4).
  • Page 13 Is the DTI2 pack Disable the DTI2 pack. Remove the carrier cable and install the loopback plug (Chart 3-3). Reset the error counters and enable the DTI2 pack. Does the NEA LED remain out? Disable the DTI2 pack. Restore the cabling. At the Office Repeater Bay, connect the line monitor to the receive...
  • Page 14 2 - 8 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Is the signal present? Restore cabling to normal. Problem is likely with Receive cabling pair between the Office Repeater Bay and the DTI2 pack (Rx-D to Rx-A). Restore cabling to normal.

  • Page 15: Loopback Alarm Led Lit

    Loopback Alarm LED Lit DTI2 loopback LED is lit Load overlay 60. Check the DTI2 pack status. Are any of the channels or the DTI2 pack itself in loopback? Disable the DTI2 pack and run the DTI2 self test (Chart 3-4). Page 2-10 Trouble analyzing procedures Remove the channel/DTI2...
  • Page 16 2-10 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Is the LED off? Disable the DTI2 pack. Unseat the pack from the back panel, then re-install. Do all the LEDs flash on and off? Chart 3-1 Enable the DTI2 pack. Enable the DTI2 pack.

  • Page 17: Disable (Dis) Alarm Led Lit

    Disable (DIS) Alarm LED Lit DTI2 Pack DIS LED is lit. Are any other LEDs lit? Load overlay 60. Run the DTI2 self test (Chart 3-4). Is the DTI2 pack Step 7 Page 2-12 Trouble analyzing procedures 2-11 Refer to: Page 2-1 (for OOS), Page 2-3 (for FEA), Page 2-6 (for NEA),...

  • Page 18: Violation Error Messages

    2-12 Trouble analyzing procedures Violation Error Messages Note: • Bipolar Violation Error: DTAXXX L BV • Coded Mark Inversion Violation Error: DTAXXX L CV 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Replace the DTI2 pack (Chart 3-1). Error Message Formats: Violation Error message: where XXX is 210, 211, 212,...
  • Page 19 Signal present? Using line monitor (Chart 3-3), monitor RECEIVE pair at the DTI2 pack (Rx-A). Signal present? Disable DTI2. Clear error counts. Remove carrier cable and install loopback plug (Chart 3-3). Enable DTI2. Step 10 Page 2-14 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Trouble analyzing procedures Suspect problem with carrier or the far end.
  • Page 20 2 - 1 4 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Are the BPV counts increasing? Replace the DTI2 pack (Chart 3-4). Suspect problem with the carrier or the far-end.

  • Page 21: Slip Error Message

    SL-1 a Master in the synch hierarchy? Both packs OK? Step 7 Page 2-12 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Trouble analyzing procedures Far End is not locked to this Meridian SL-1. Replace faulty pack (Chart 3-1/Chart 3-2). 2-15...
  • Page 22 2-16 Trouble analyzing procedures Replace DTI2/Clock Controller cable. Problem still present? Replace DTI2 and/or Clock Controller pack(s) (Chart 3-1/ Chart 3-2). 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Restart system.

  • Page 23: Frame Alignment Error Message

    Frame Alignment Error Message Frame Alignment Error message: DTAXXX L FV on TTY, where XXX is 210, 211, 212, 216, 217 or 218 and L is the loop number. Using line monitor (Chart 3-3), monitor RECEIVE pair at the office repeater bay (Rx-D).
  • Page 24 2-18 Trouble analyzing procedures 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 Is the signal present? Disable the DTI2 loop and run the self test (Chart 3-4) Is the DTI2 pack Fault possibly with the Receive pair between the main cross- connect terminal and the DTI2 pack.

  • Page 25: Dti2/Dmi Pack Replacement

    DTI2/DMI Pack Replacement Chart 3-1 Replacement of Digital Interface circuit pack Firmly touch the metal frame of the cabinet to discharge static electricity from your body before handling circuit packs Step Pack Removal: Installation CAUTION P r o c e d u r e Disable the Network Loop, using Overlay 60.

  • Page 26: Clock Controller Pack Replacement

    3 - 2 Replacement, Monitor and Test procedures Chart 3-1 (continued) Replacement of Digital Interface circuit pack Step Clock Controller pack replacement C h a r t 3 - 2 Replacement of Clock Controller circuit pack Note: Do not deviate from this procedure. This procedure will not cause Firmly touch the metal frame of the cabinet to discharge static electricity from your body before handling circuit packs 2 Mb/s DTI Fault Clearing Procedures 553-2911-510...
  • Page 27 3 - 4 Replacement, Monitor and Test procedures Chart 3-2 (continued) Replacement of Clock Controller circuit pack Step 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 P r o c e d u r e Ensure that the Clock Controller card being replaced is associated with the inactive CPU.
  • Page 28 Replacement, Monitor and Test procedures 3 - 5 Use Overlay 60 to verify normal service level. First; switch the active clock to standby. The command is SWCK 'n'. Next; check the status of the new Clock Controller. The command is SSCK 'n'. If a trouble is indicated by the response, refer to NTP 553-2301-511 for an interpretation of the message.

  • Page 29: 2.048 Megabit Pcm Line Monitor

    3 - 6 Replacement, Monitor and Test procedures 2.048 Megabit PCM line monitor C h a r t 3 - 3 2.048 Megabit PCM line monitor Step 2 Mb/s DTI Fault Clearing Procedures 553-2911-510 P r o c e d u r e To monitor the DTI 2.048 Mb/s pcm data stream, use: SIGNAL MONITOR, •...

  • Page 30: Verification Tests For Dti2/Dmi And Cc Packs

    Verification tests for DTI2/DMI and CC packs C h a r t 3 - 4 V e r i f i c a t i o n t e s t s f o r D T I 2 / D M I a n d C C p a c k s Verification test for DTI circuit pack Step 2.

  • Page 31: Copyright Statement

    Family Product Manual Contacts Copyright FCC notice Trademarks Document number Product release Document release Date Publish Copyright Statement © 1998 Northern Telecom All rights reserved Information is subject to change without notice. Northern Telecom reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant.
