Figure 32 : Maintenance cable
CMRC
CMCC CMRC CMLC CMLC CMBC CMBC
CMLC
SP
Controller radio line
radio line line line line base base
card
card card card card station station
card card
ribbon socket for
cable connection of
maintenance cable
card to be removed
