Northern Telecom Meridian 1 Installation And Maintenance Manual page 64

Page 54 of 220 Installing the hardware
Table 10 : NT8D11 CE/PE Module—Line card pair-terminations for connectors A, B, E, H
(standard)
Pair Pins
1T / 1R 26 / 1
2T / 2R 27 / 2
3T / 3R 28 / 3
4T / 4R 29 / 4
5T / 5R 30 / 5
6T / 6R 31 / 6
7T / 7R 32 / 7
8T / 8R 33 / 8
9T / 9R 34 / 9
10T / 10R 35 / 10
11T / 11R 36 / 11
12T / 12R 37 / 12
13T / 13R 38 / 13
14T / 14R 39 / 14
15T / 15R 40 / 15
16T / 16R 41 / 16
17T / 17R 42 / 17
18T / 18R 43 / 18
19T / 19R 44 / 19
20T / 20R 45 / 20
21T / 21R 46 / 21
22T / 22R 47 / 22
23T / 23R 48 / 23
24T / 24R 49 / 24
25T / 25R 50 / 25
553-3601-200 Standard 7.00 November 1998
Pair color
W-BL / BL-W
W-O / O-W
W-G / G-W
W-BR / BR-W
W-S / S-W
R-BL / BL-R
R-O / O-R
R-G / G-R
R-BR / BR-R
R-S / S-R
BK-BL / BL-BK
BK-O / O-BK
BK-G / G-BK
BK-BR / BR-BK
BK-S / S-BK
Y-BL / BL-Y
Y-O / O-Y
Y-G / G-Y
Y-BR / BR-Y
Y-S / S-Y
V-BL / BL-V
V-O / O-V
V-G / G-V
V-BR / BR-V
V-S / S-V
I/O panel connectors/slot
A B E
slot 0 slot 1 slot 4
slot 2 slot 5
Unit 16/card
H
slot 7
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
slot 8
0
1
2
3
4
5
6
7
Spare
