DiGidot USB Power Cable
Art. no.: 20331
Power cable to connect DiGidot C4 to 5 Vdc USB port (included with DiGidot C4 Extended)
‣
DiGidot DIN-Rail Clip
Art. no.: 20902
Optional DIN-rail Mounting Clip for DiGidot C4
‣
DiGidot 8GB microSD Card
Art. no.: 20901
Industrial grade spare microSD memory card for DiGidot C4 Extended (included with DiGidot
‣
C4 Extended)
DiGidot RJ45 DMX Adapter
Art. no.: 20329
Connects to a network cable that runs prom a PxLNet Transmitter port and can be plugged in
‣
any DMX controlled product with an XLR-3 socket.
For further DiGidot products, Transceiver kits and accessories visit our website www.digidot.eu.

VARIOUS

Online resources

For technical specifications, latest documentation, manuals, product information, support and
upgrades, please visit www.digidot.eu.

Remarks

We've put great care in writing this manual. However in case you encounter any discrepancies or
unclarities, please contact us. This manual and feature specific instructions are based on firmware
and interface versions mentioned in the chapter 'Manual version'.
NOTE: This manual covers information for the DiGidot C4 Live and Extended controllers. In case of C4
Live controllers, some of the features may not be displayed in the user interface because they are
limited to the Extended version only (refer to appropriate symbols in this manual).

Terminology

SPI
IC
C4 Manual
Serial Peripheral Interface; This is an interface bus between that is used
to send data between microcontrollers and IC's.
Integrated Circuit; this is an electronic component which houses a ready
made circuit that is able to perform one specific task. An IC can be
placed separately on a PCB or integrated in a LED package to
control/drive a LED or segment/array of LEDs.
Version 2.1.5 71 74 -
